Advance Tabco HDCPU-5-DR Triumph (Supreme) Serving Counters
Advance Tabco HDCPU-5-DR Triumph (Supreme) Serving Counters is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Advance Tabco HDCPU-5-DR Triumph (Supreme) Serving Counters
Description
Advance Tabco Triumph (Supreme) Heavy-Duty Ice-Cooled Serving Counter – 5-Pan (HDCPU-5-DR)
77-3/4" W × 36-1/4" D × 35" H | NSF ListedEngineered for high-volume cafeterias, buffets, and catering lines, the Triumph Supreme ice-cooled counter keeps salads, desserts, and grab-n-go entrées perfectly chilled while offering a rugged, fully enclosed storage base for back-up product and smallwares.
Key Features
- Holds (5) full-size 12" × 20" pans up to 6-1/4" deep (pans sold separately).
- 8" deep, 18 ga. 302 stainless steel ice well with fiberglass insulation for superior cold retention.
- Integrated 1" IPS drain for fast ice melt removal.
- 8"-deep stainless steel plating shelf with removable 3/8" white poly cutting board.
- 18 ga. 304 stainless steel enclosed base with fixed undershelf and two smooth-glide sliding doors.
- All-welded heavy-duty construction; ships knocked-down with legs and cutting board packaged separately.
- Four 16 ga. stainless steel legs with fully adjustable bullet feet for rock-solid leveling.
- NSF certified for open foodservice use.
At-a-Glance Specifications
| Manufacturer / Model | Advance Tabco HDCPU-5-DR (Triumph Supreme Series) |
|---|---|
| Overall Dimensions | 77-3/4" W × 36-1/4" D* × 35" H *Depth includes cutting board. |
| Ice Well Interior | 70" W × 19-1/4" D × 8" H |
| Pan Capacity | (5) 12" × 20" full pans (accepts fractional pans with optional adapter rails) |
| Cutting Board | 3/8" thick white thermoplastic; removable for cleaning |
| Base Construction | 18 ga. 304 SS cabinet, fixed undershelf, (2) sliding doors |
| Drain | 1" IPS brass drain with plug |
| Legs / Feet | (4) 16 ga. stainless legs with adjustable stainless bullet feet |
| Shipping Weight | ≈ 264 lb. |
| Certifications | NSF |
Optional Accessories (sold separately)
- SU-P-505 adapter rail kit – use fractional pans for versatile layouts.
- TBS-5 double-sided buffet shelf with acrylic sneeze guard.
- TSS-5 single-sided cafeteria shelf with built-in food shield.
- Acrylic side panels for additional NSF compliance.
Looking for a complete serving line or custom fabrication? Contact our equipment specialists for complimentary layout assistance and lead-time information.
