Advance Tabco 54" x 18" x 4" 14-Gauge 304 Stainless Steel Floor Trough with Subway-Style Grating

Non Anti-Splash Design, Built-In Floor Installation

A durable 54-inch floor trough built from 14-gauge 304 stainless steel, with subway-style grating and a removable strainer basket for reliable floor drainage.

  • 54" x 18" x 4" floor trough sized for efficient drainage in commercial floor applications.
  • 14-gauge 304 stainless steel construction helps deliver long-lasting corrosion resistance.
  • Includes stainless steel subway-style grating made from solid 304 stainless steel bars.
  • Removable perforated strainer basket with handle helps capture debris and simplify cleaning.
  • Pitched toward the waste outlet to promote positive drainage.
  • Designed for tile installation with a perimeter flange and vertical step.

Overall Dimensions:

54.0"W x 18.0"D x 4.0"H

Product Weight:

122.0 lb

14-Gauge 304 Stainless Steel Construction

Heavy-duty stainless steel construction provides strength and corrosion resistance for demanding floor drainage use.

Subway-Style Stainless Steel Grating

Includes stainless steel grating made from 3/16" x 1" solid 304 stainless steel bars with 9/16" clear spacing.

Removable Strainer Basket

A perforated stainless steel strainer basket with handle is included to catch debris and simplify maintenance.

Positive Drainage Design

The trough is creased and pitched toward the waste outlet to help move water efficiently.

4-Inch Waste Pipe Compatibility

Accommodates up to a 4" waste pipe and includes a 4" O.D. x 3" long plumbing sleeve.

Tile-Ready Installation

Perimeter flange mounts directly to the subfloor, and a 3/4" vertical step accommodates floor tile installation.

TIG-Welded Construction

All TIG welded with external corners welded and polished to a satin finish for a clean, durable build.

Type Floor Trough
Style Non Anti-Splash
Installation Type Built-In
Material 304 Stainless Steel
Finish Satin Finish
Drain Connection Size 4 Inches O.D.
Drain Connection Required
Selling Unit Each
Units Per Case 1
Shipping Width 54 Inches
Shipping Depth 18 Inches
Shipping Height 4 Inches
Shipping Weight 122 Pounds

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download

Frequently Asked Questions

It measures 54 inches wide, 18 inches deep, and 4 inches high.
The trough is made from 14-gauge 304 stainless steel with stainless steel grating.
Yes, a removable perforated stainless steel strainer basket with handle is included.
It accommodates up to a 4-inch waste pipe and includes a 4-inch O.D. x 3-inch long plumbing sleeve.
Yes, it includes a perimeter flange and a 3/4-inch vertical step to accommodate floor tile installation.
Yes, custom sizes are available; consult the factory for options.
