Advance Tabco FC-WM-60-ADA Hand Sinks
Description
Advance Tabco FC-WM-60-ADA Multi-Station Hand Sink
60" W • 3 Stations • ADA Compliant • 16 ga 304 Stainless SteelBuilt for high-volume hand-washing where accessibility and hygiene are non-negotiable, the FC-WM-60-ADA delivers rugged Advance Tabco quality in a wall-mounted, three-person configuration that meets ADA knee-clearance requirements. From commercial kitchens to industrial plants and schools, this NSF-listed sink provides a sanitary, easy-to-clean solution that maximizes floor space and workflow.
Why You’ll Love It
- ADA bowl depth – 5" deep to provide the necessary knee clearance for seated users.
- Oversized 60" wide deck with three stations, each pre-punched 8" on-center for splash-mount faucets (faucets sold separately).
- 16 ga type 304 stainless steel throughout, TIG-welded and blended to a smooth satin finish.
- 16" front-to-back bowl interior offers generous hand-washing space without protruding into aisles.
- 8-1/2" high integral backsplash contains splashes and speeds clean-up.
- Includes one 3-1/2" K-6 rear basket drain—no need to source separately.
- Stainless steel “Z” wall brackets and 1-5/8" tubular stainless steel supports create full open clearance underneath for wheelchairs, carts or cleaning equipment.
- NSF listed for food-service sanitation and designed for long-term, heavy-duty use.
At-a-Glance Specs
| Model | FC-WM-60-ADA (No faucets included) |
|---|---|
| Overall Dimensions | 60" W × 19-1/2" D × 25-1/2" H |
| Bowl Size (each station) | 16" F/B × 5" Deep |
| Backsplash Height | 8-1/2" |
| Stations | 3 |
| Faucet Holes | (3) sets, 8" on-center, 1-1/4" diameter |
| Drain Size / Type | 3-1/2" K-6 rear basket drain (included) |
| Material & Gauge | 16 ga type 304 stainless steel |
| Mounting Hardware | Stainless “Z” wall brackets & tubular supports (included) |
| Certifications | NSF, ADA compliant |
Fast, Secure Installation
- Mount “Z” brackets to wall studs or masonry at 42-1/2" from finished floor to bracket top.
- Slide sink onto brackets—no legs needed, leaving the floor completely open.
- Connect water lines to your choice of 8" O.C. splash-mount faucets and attach the included basket drain to waste line.
Faucets, traps and supplies are sold separately so you can choose manual, knee-, toe-push or electronic controls that best suit your operation.
