Advance Tabco FC-2-1824-18R Compartment Sinks
Description
Advance Tabco Fabricated 2-Compartment Sink – 18" Right Drainboard
Model FC-2-1824-18R | 16 Gauge 304 Stainless Steel | NSFEngineered for demanding prep and wash stations, this heavy-duty Advance Tabco sink pairs two spacious bowls with a convenient right-hand drainboard―all in a compact 29-½" front-to-back footprint. Fully TIG-welded 16 ga. 304 stainless steel, a rolled rim edge, and rock-solid leg bracing ensure years of worry-free service.
Key Features & Benefits
- Two 18" × 24" × 14" deep fabricated bowls for high-volume washing or rinsing.
- 18" right-side drainboard keeps clean wares organized and off the worktop.
- Tile-edge 8-½" backsplash mounts flush to wall surfaces for a sanitary, caulk-free seal.
- Rolled rim edge reinforces the sink top while providing a smooth, comfortable work surface.
- Pre-punched 8" on-center faucet holes fit most commercial faucets (sold separately).
- (2) 1-½" IPS basket drains in bowl centers are included—no add-ons required.
- 1-⅝" Ø stainless steel legs with adjustable side cross-bracing prevent sway.
- 1" adjustable stainless steel bullet feet make easy work of leveling on uneven floors.
- NSF certified—ideal for restaurants, commissaries, laboratories, and schools.
Product Specifications
| Compartments | 2 |
|---|---|
| Bowl Interior (each) | 18" W × 24" L × 14" D |
| Drainboard | 18" (right-hand) |
| Overall Dimensions | 56-½" L × 29-½" F/B × 43" H (to top of backsplash) |
| Backsplash Height | 8-½" with tile edge |
| Material Thickness | 16 ga. type 304 stainless steel |
| Faucet Mounting | (2) 1-⅛" dia. holes on 8" centers |
| Drain Connections | (2) 1-½" IPS basket strainers (included) |
| Legs / Bracing | 1-⅝" Ø S/S legs with adjustable side cross-bracing |
| Feet | 1" adjustable stainless steel bullet feet |
| Approx. Shipping Weight | ≈ 130 lb |
| Certifications | NSF |
Looking for custom bowl sizes or additional drainboards? Ask our team about Advance Tabco’s Smart Fabrication™ program for quick, factory-built modifications.
