Advance Tabco FC-1-1818-18RL Compartment Sinks
Description
Advance Tabco FC-1-1818-18RL Fabricated Sink
1-Compartment • Dual 18" Drainboards • NSF ListedBuilt to thrive in busy commercial kitchens, the FC-1-1818-18RL combines a full–size 18" x 18" sink bowl with right- and left-mounted drainboards for true workstation versatility. Heavy-duty 16 ga. type 304 stainless steel, TIG-welded construction, and reinforced rolled edges deliver years of worry-free service while meeting the latest NSF sanitation standards.
Key Performance Features
- One deep 18" × 18" × 14" bowl handles oversized pots and sheet pans.
- 18" drainboards on both sides speed up prep, wash, and drying cycles.
- 16 gauge, 304 stainless steel resists corrosion and daily wear.
- TIG-welded seams are blended to a smooth satin finish for easy cleaning.
- Rolled rim edge adds strength and protects against bumps & dents.
- Tile-edge 8" backsplash simplifies installation and creates a watertight seal.
- Pre-punched 8" on-center faucet holes accept most commercial faucets (sold separately).
- 1 ½" IPS stainless steel basket drain included; centered for optimal flow.
- 1 ⅝" Ø stainless steel legs with adjustable side cross-bracing for rock-solid stability.
- 1" adjustable stainless steel bullet feet level the unit on uneven floors.
At-a-Glance Specifications
| Model | FC-1-1818-18RL |
|---|---|
| Compartments | (1) 18" × 18" × 14" fabricated bowl |
| Drainboards | (2) 18" L – right & left |
| Overall Dimensions | 54" L × 24" F/B × 43" H (to splash top) |
| Backsplash | 8 ½" H with 1" return; tile-edge |
| Material Thickness | 16 ga. (0.062") type 304 stainless steel |
| Faucet Holes | 8" on-center, 1" Ø |
| Water Supply | ½" IPS hot & cold (connections by others) |
| Waste Opening | 1 ½" IPS, basket drain furnished |
| Legs / Bracing | 1 ⅝" Ø S/S tubular legs with adjustable side cross-bracing |
| Feet | 1" adjustable stainless steel bullet feet |
| Shipping Weight | Approx. 90 lb |
| Certifications | NSF |
What’s Included
- Advance Tabco FC-1-1818-18RL fabricated sink
- Stainless steel basket drain assembly
- Pre-installed legs, side cross-bracing, and bullet feet
Optional Add-Ons
- Wall-mount or deck-mount faucets (8" OC)
- Removable side splashes (model K-700)
- Lever-operated drains & overflow assemblies
- Custom cutting boards and drainboard shelves
Contact our team for compatible accessories and professional installation guidance.
