Advance Tabco  |  Special Value Series  |  SKU: DTC-3-90R-X

Advance Tabco DTC-3-90R-X Special Value Series Compartment Sinks

$2,205.60
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet
Related Searches
Commercial Work Tables Restaurant Equipment Sink Tables Specialty Work Tables

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco Special Value Series 90" 3-Compartment Dishtable – Right Side (DTC-3-90R-X)

Attaches to the operator’s right side of most standard dish machines

Built for high-volume warewashing areas, this Special Value Unit combines a full 3-compartment sink, a 7 ½" backsplash and a 16" drainboard into a single, space-saving workstation. Heavy-duty 16 gauge, 304 stainless steel construction makes the DTC-3-90R-X tough enough for everyday commercial use while TIG-welded seams and satin-finished welds maintain a polished, professional look.

Key Features

  • (3) 18" W x 24" L x 14" D sink bowls – positioned 20" from the dish machine for easy loading
  • 16" right-hand drainboard with pitched surface for rapid draining
  • 7 ½" backsplash with 2" return and pre-punched 8" O.C. faucet holes (faucet sold separately)
  • 16 gauge, type 304 stainless steel top for superior corrosion resistance
  • Stainless steel legs with welded front-to-back crossrails & adjustable front cross brace
  • Stainless steel bullet feet for fast, level installation
  • Includes (3) K-6 basket drains, (2) wall clips & K-4 lever-drain brackets (lever drains optional)
  • NSF listed – ideal for regulated food-service environments

Specifications

Model DTC-3-90R-X
Overall Length 90"
Overall Depth 30"
Bowl Size (W × L × D) 18" × 24" × 14"
Drainboard 16" right side
Backsplash Height 7 ½"
Material / Gauge 304 stainless steel / 16 ga
Faucet Holes (1) set, 8" centers
Drain Outlet 1 ½" I.P.S. per bowl
Approx. Weight 250 lb.
Important: Before ordering, verify your dish machine’s control box and side panels will clear the 20" bowl offset. Refer to Advance Tabco’s dish machine compatibility chart or contact us for assistance.

Popular Accessories (Sold Separately)

  • DTA-53 pre-rinse faucet with twist handle
  • K-5 twist-handle operated drain (2" I.P.S.)
  • Lever-operated drains to pair with included K-4 brackets

Faucet, lever drains and pre-rinse sprayer are not included unless added above.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Special Value Series

Certifications

NSF

Height

41.5in

Width

90.0in

Depth

30.0in

Shipping Weight

250.0lbs

Dish Machine Location

left side

Compartment (side - side)

18"

Width (side - side) OA

85" - 96"

Dishtable Splash

7-1/2"

Dishtable Shape

straight

Gauge

16 ga

Type Stainless Steel Top

300 series

Compartment (front - back)

24"

Dishtable Legs

stainless steel

Specifications

Special Value Dishtable with 3-compartment Sink, 90”W, (3) 18" x 24" x 14" bowls, 16 gauge 304 stainless steel top, stainless steel legs, adjustable front cross bracing & welded front-to-back crossrails, attaches to right of dish machine operator, stainless steel bullet feet, 16" right drainboard, bowls are located 20" from machine, NSF (must verify machine to make sure the control box does not interfere) (Special Value NET Pricing)
