Advance Tabco CU-24-108-2 Stainless Steel Shelving
Description
Advance Tabco CU-24-108-2 Double-Tier Overshelf
108" W x 24" D • 18 ga Type 430 Stainless Steel • NSFAdd a full 18 ft2 of easily accessible storage above your existing cookline, prep table or dish station without sacrificing an inch of valuable floor space. This rugged, two-tier overshelf spans 108 inches and is engineered to mount directly to the equipment you already own, giving you the flexibility to keep pans, smallwares and countertop appliances right where you need them.
Key Features
- Double-tier design doubles your usable storage area.
- Constructed from 18 gauge, type 430 stainless steel with a satin finish for lasting corrosion resistance and easy cleaning.
- All TIG-welded with polished welds for a seamless, sanitary appearance.
- NSF certified for food-zone applications.
- Includes three sets of heavy-duty stainless steel posts (required on shelves 96" and longer) for superior rigidity.
- Choice of Surface Mount or Edge Mount brackets—factory-located to match your equipment layout.
- Accepts 1" or 1 5⁄8" round tubing to integrate with existing table legs (specify when ordering).
Specifications
| Manufacturer / Model | Advance Tabco CU-24-108-2 |
|---|---|
| Shelf Style | Table-mounted, double tier |
| Overall Length (L) | 108 in (2743 mm) |
| Overall Depth (W) | 24 in (610 mm) |
| Shelf Gauge / Material | 18 ga Type 430 stainless steel |
| Finish | Satin polish |
| Supports | (3) Stainless steel post sets, TIG welded |
| Mounting Options | Surface Mount or Edge Mount brackets (factory located) |
| Shipping Weight | ≈ 239 lb (108 kg) |
| Certifications | NSF |
Mounting Bracket Details
- Surface Mount: Attaches to the tabletop or equipment top with customer-supplied fasteners.
- Edge Mount: Clamps to the rear edge of the table for a clean, drill-free installation.
- Standard clearance: 13 1⁄2" (18" wide shelves) or 19 1⁄2" (24" wide shelves) between posts.
- Bracket hole diameter: 5⁄16" for ¼" hardware.
Popular Factory Options
- Custom lengths over 12' (Model TA-104)
- Special shelf sizing or cut-outs (Model TA-60)
- 24" × 24" microwave extension shelf (Model TA-102)
Need a different size or configuration? Advance Tabco’s Smart Fabrication™ team can build nearly any custom overshelf. Contact us for a quote.
