Advance Tabco 144" x 18" Single-Tier Stainless Steel Overshelf
Model CU-18-144 • NSF ListedInstantly create a clean, professional storage tier above a 12 ft. cookline, prep table, or refrigeration suite. Designed to mount directly to the equipment you already own, this heavy-duty overshelf keeps pans, spices, utensils, and small appliances right where you need them—without giving up a single square inch of floor space.
Key Benefits
- Full 144 in. (12 ft) span—ideal for long cooklines and servery counters.
- 18 in. depth offers generous work-side reach without crowding the back line.
- 18 ga type 430 stainless steel shelf with satin polish resists corrosion and cleans up fast.
- All TIG-welded construction for maximum rigidity and long service life.
- (3) sets of stainless steel supports included—required on shelves 96 in. and longer for rock-solid stability.
- Choice of mounting style:
- Surface Mount – bolts through the top of existing equipment.
- Edge Mount – clamps to the rear edge with minimal top-side intrusion.
- Heavy-duty posts—specify 1 in. or 1 5⁄8 in. diameter to match site requirements.
- NSF certified for use in all commercial foodservice environments.
At-a-Glance Specs
| Overall Length | 144 in. (3,657 mm) |
|---|---|
| Overall Depth | 18 in. (457 mm) |
| Shelf Height | Custom – specify when ordering |
| Material | 18 ga type 430 stainless steel |
| Finish | Satin polish |
| Supports | (3) stainless steel support sets (included) |
| Post Diameter | Choose 1 in. or 1 5⁄8 in. |
| Mounting Options | Surface mount or edge mount (hardware included) |
| Approx. Net Weight | 130 lb (59 kg) |
| Certification | NSF |
Ordering & Customization
- Submit equipment model numbers and a dimensional drawing so our engineers can locate mounting points.
- Specify desired shelf height and post diameter.
- Need something special? Optional factory modifications include:
- Non-standard shelf sizing (TA-60)
- 24 in. x 24 in. microwave extension shelf (TA-102)
- Lengths beyond 12 ft (TA-104)
- Smart Fabrication™ quotes available—email smartfab@advancetabco.com.
Important: This overshelf is built to span over existing equipment.
Please provide complete model numbers and a print of the equipment during checkout
so mounting brackets can be fabricated correctly. Orders without this information may delay production.
Manufactured in the USA by Advance Tabco – a leader in stainless steel fabrication since 1929.
$1,577.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Advance Tabco CU-18-144 stainless steel overshelf 144" x 18" (18/430) NSF-rated—durable, corrosion‑resistant span shelf to fit over existing equipment.
Manufacturer
Advance Tabco
Certifications
NSF
Width
144.0in
Depth
18.0in
Shipping Weight
130.0lbs
Construction
stainless steel
Depth (front - back)
18"
Shelves
single
Gauge
18 gauge
Width (side - side)
133" - 144"
Specifications
Overshelf, single, 144"W x 18"D, 18/430 stainless steel, to span over existing equipment (supplied by others), NSF (must provide equipment model numbers that shelf is going over to clarify mounting provision)
