Advance Tabco  |  SKU: CU-18-144-2  |  UPC: 747545116420

Advance Tabco CU-18-144-2 Stainless Steel Shelving

$2,556.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet
Related Searches
Stainless Steel Shelving Storage & Shelving

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco CU-18-144-2 Double-Tier Overshelf

144" W x 18" D | 18 ga 430 Stainless Steel | NSF Listed

Turn the unused vertical space above your existing cookline or worktable into two levels of rugged, sanitary storage. The CU-18-144-2 overshelf spans a full 12 ft (144") and is built to handle the everyday demands of busy commercial kitchens.

Stand-out Benefits

  • Two full-length 18 ga shelves provide generous dry storage without increasing your footprint.
  • All TIG-welded construction with exposed surfaces polished to an easy-clean satin finish.
  • Choice of Surface-Mount or Edge-Mount brackets to match your existing table or equipment line-up.
  • Heavy-duty stainless steel posts (specify 1" or 1 5⁄8" Ø) and three support sets ensure rock-solid stability on all 12 ft units.
  • NSF certified for open-kitchen installation and food-contact safety.
  • Made in the USA by Advance Tabco—industry leader in smart fabrication solutions.

Detailed Specifications

Model CU-18-144-2
Overall length 144" (365.8 cm)
Shelf depth (front-to-back) 18" (45.7 cm)
Number of tiers 2
Material & gauge 18 ga type 430 stainless steel shelves
Stainless steel posts & brackets
Finish Satin polish
Supports supplied 3 sets (center + ends) for 96" & longer units
Mounting options Surface-Mount or Edge-Mount (select when ordering)
Approx. weight 298 lb (135 kg)
Certifications NSF

Popular Modifications (factory-installed)

  • TA-60 – Custom shelf sizing
  • TA-102 – 24" × 24" microwave extension shelf
  • TA-104 – Additional length beyond 12 ft
Important Ordering Note: This overshelf is engineered to mount over existing equipment/tables supplied by others. Please provide the exact make & model numbers—and a dimensional drawing if available—so our fabrication team can locate the mounting brackets correctly.
A shop print approval may be required prior to production.

Need help configuring your shelf? Call Advance Tabco Customer Service at 1-800-645-3166 (Mon–Fri, 8:30 am–7:00 pm EST) or email customer@advancetabco.com.

Features & Specs

Manufacturer

Advance Tabco

Certifications

NSF

Width

144.0in

Depth

18.0in

Shipping Weight

298.0lbs

Construction

stainless steel

Depth (front - back)

18"

Width (side - side)

133" - 144"

Shelves

double

Gauge

18 gauge

Specifications

Overshelf, double, 144"W x 18"D, 18/430 stainless steel, to span over existing equipment (supplied by others), NSF (must provide equipment model numbers that shelf is going over to clarify mounting provision)
