Advance Tabco  |  SKU: CU-18-120  |  UPC: 747545116376

Advance Tabco CU-18-120 Stainless Steel Shelving

$1,449.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco 120" x 18" Single-Tier Stainless Steel Overshelf

Model CU-18-120  |  NSF Listed

Unlock the unused vertical space above your 10-ft cookline, prep table, or refrigerated base. This heavy-duty Advance Tabco overshelf mounts directly to your existing equipment, providing a sanitary, easy-to-reach storage level that is built to thrive in demanding commercial kitchens.

Key Features

  • Generous 120" L x 18" D single shelf spans an entire cookline or extra-long work table.
  • 18-gauge type 430 stainless steel with a food-safe satin polish for effortless cleanup.
  • All TIG-welded construction delivers rock-solid rigidity and long service life.
  • Includes heavy-duty stainless posts – choose 1" or 1 5⁄8" O.D.
  • Select Surface-Mount or Edge-Mount brackets to match your table or curb profile.
  • Three (3) intermediate support sets supplied on units 96" and longer to prevent sag.
  • NSF listed for use in food-zone applications.

Specifications

Model CU-18-120 (Single Tier)
Overall length 120" (3048 mm)
Shelf depth 18" (457 mm)
Shelf height 12" standard clearance from equipment top (custom heights available)
Material / gauge 18-ga. type 430 stainless steel
Finish Satin polish on all exposed surfaces
Mounting Surface-Mount or Edge-Mount brackets (factory located)
Support posts Stainless steel, 1" or 1 5⁄8" O.D.
Supports 3 sets of intermediate supports
Approx. shipping weight 105 lbs (48 kg)
Certifications NSF

Ordering & Installation Notes

  • A dimensioned drawing or CAD file is required for fabrication; please email with your PO.
  • List the make & model numbers of every piece of equipment the shelf will span so mounting holes and clearances can be factory-engineered.
  • Units longer than 12' require TA-104 extended-length modification – contact us for a quote.
  • Optional add-ons: special shelf sizing (TA-60) or 24" × 24" microwave extension (TA-102).
Production Hold: A signed approval drawing confirming mounting style, post diameter, clearance, and equipment model numbers is required before the shelf can be scheduled for manufacture.

Features & Specs

Manufacturer

Advance Tabco

Certifications

NSF

Width

120.0in

Depth

18.0in

Shipping Weight

105.0lbs

Construction

stainless steel

Width (side - side)

109" - 120"

Shelves

single

Depth (front - back)

18"

Gauge

18 gauge

Specifications

Overshelf, single, 120"W x 18"D, 18/430 stainless steel, to span over existing equipment (supplied by others), NSF (must provide equipment model numbers that shelf is going over to clarify mounting provision)
