Advance Tabco 93-84-80-36R Regaline Compartment Sinks
Description
Advance Tabco “Regaline” 4-Compartment Sink with 36" Right-Hand Drainboard
20" W x 28" F/B x 12" D Bowls • 16 ga 304 Stainless Steel • NSFBuilt for high-volume ware-washing and prep, the Regaline series combines Advance Tabco’s one-piece deep-drawn bowls with a heavy-duty open frame base—delivering seamless sanitation, rock-solid stability and streamlined workflow in the busiest commercial kitchens.
Key Features & Benefits
- Four (4) seamless sink compartments—each 20" W x 28" F/B x 12" D—for efficient wash, rinse, sanitize & soak zones.
- 36" right-hand drainboard with pitched ribs speeds drying and staging.
- Durable 16 gauge type 304 stainless steel resists corrosion and heavy abuse.
- 8" high backsplash with tile-edge rim helps contain splashes and simplifies wall installation.
- 1 ⅝" Ø tubular stainless steel legs with side cross-rails and stainless gussets provide exceptional rigidity.
- 1" adjustable stainless steel bullet feet ensure a level, code-compliant set-up on uneven floors.
- Generous 3" radius bowl corners promote fast, thorough cleaning.
- All TIG-welded construction; welds are blended to a smooth, sanitary satin finish.
- NSF listed for food-service sanitation.
At-a-Glance Specifications
| Compartments | 4 |
|---|---|
| Interior bowl size (W × F/B × D) | 20" × 28" × 12" |
| Drainboard | 36" right-hand, integrally welded (includes two additional support legs) |
| Backsplash height | 8" |
| Overall dimensions | 130" L × 32" F/B × approximately 44" H (to top of backsplash) |
| Material / thickness | Type 304 stainless steel, 16 gauge |
| Legs & bracing | 1 ⅝" Ø stainless legs with adjustable side cross-rails |
| Feet | 1" stainless adjustable bullet feet |
| Drain openings | (4) 1 ½" IPS stainless basket drains (included) |
| Faucet holes | (2) sets on 8" centers – faucets sold separately |
| Certifications | NSF |
| Approx. shipping weight | ≈ 355 lb. |
Need custom modifications or accessories (cutting boards, sink covers, lever drains)? Contact our team for a fast Smart Fabrication™ quote.
