Advance Tabco 93-84-80-24R Regaline Compartment Sinks
Description
Regaline 4-Compartment Sink with Right-Hand Drainboard
Advance Tabco Model 93-84-80-24R • NSF ListedEngineered for high-volume ware-washing, the Advance Tabco Regaline series marries heavy-duty 16 ga. 304 stainless steel with seamless TIG-welded construction. Four spacious bowls plus a full-size right-hand drainboard maximize workflow for washing, rinsing, sanitizing and air-drying – all in one rock-solid, code-compliant station.
Key advantages
- Four 28" F/B × 20" W × 12" D bowls handle sheet pans, stock pots and hotel pans with ease.
- One-piece deep-drawn bowls feature generous 3" inner corner radii for fast, thorough clean-up.
- Full 24" right-hand drainboard supports heavy racks and equipment without flex.
- 8" high backsplash with tile edge protects walls and simplifies installation.
- Open frame base with 1 5/8" Ø stainless legs, side cross-rails and 1" adjustable bullet feet for rock-solid stability on uneven floors.
- All TIG welds are blended to a satin finish for a smooth, snag-free surface.
- Pre-punched 8" on-center faucet holes (two faucets required) and 1 1/2" IPS basket drains included.
- NSF certified for food-service sanitation.
Technical specifications
| Model | 93-84-80-24R (Right drainboard) |
|---|---|
| Compartments | 4 |
| Bowl size (each) | 28" front-to-back × 20" wide × 12" deep |
| Drainboard | 24" right-hand, integrally welded |
| Overall dimensions | 118" left-to-right × 32" front-to-back (approx. 42" H to top of backsplash) |
| Material / gauge | 16 ga type 304 stainless steel (bowls, deck & drainboard) |
| Legs & bracing | 1 5/8" Ø tubular stainless legs with adjustable side cross-rails |
| Feet | 1" stainless adjustable bullet feet |
| Backsplash height | 8" |
| Plumbing | (2) sets of 8" O.C. faucet holes • (4) 1 1/2" IPS basket drains |
| Shipping weight | Approx. 337 lb |
| Compliance | NSF |
Need custom modifications or accessories such as lever-waste drains, splash-mounted faucets or cutting-board sink covers? Ask our team – Advance Tabco’s Smart Fabrication™ program has you covered.
