Advance Tabco  |  Regaline  |  SKU: 93-44-96-36RL  |  UPC: 747545108517

Advance Tabco 93-44-96-36RL Regaline Compartment Sinks

$7,340.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Regaline 4-Compartment Sink w/ Dual 36 in. Drainboards

Advance Tabco 93-44-96-36RL  •  16-Gauge Type 304 Stainless Steel

Engineered for the busiest commercial kitchens, the Advance Tabco Regaline 4-compartment sink combines rugged TIG-welded construction, expansive work surfaces and NSF-listed sanitation in one seamless, easy-to-install unit.

Key Advantages

  • (4) deep-drawn bowls – 24 in. x 24 in. x 12 in. each – accommodate stock pots, sheet pans and bus tubs.
  • Left & right 36 in. drainboards with integral splash accelerate both soiled and clean-ware workflows.
  • One-piece bowl/backsplash design with 3 in. radius corners eliminates hard-to-clean seams.
  • Durable 16-ga. type 304 stainless steel resists corrosion and heavy daily use.
  • Open frame base with 1 5⁄8 in. O.D. tubular legs, side cross-rails and eight legs (two extra under each 36 in. drainboard) for superior stability.
  • 1 in. adjustable stainless steel bullet feet level the sink on uneven floors.
  • Pre-punched 8 in.-on-center faucet holes – two faucet sets required (sold separately).
  • 1 ½ in. IPS stainless steel basket drains furnished and installed in bowl centers.
  • Tile-edge 8 in. backsplash simplifies wall mounting and contains splashes.
  • NSF listed – approved for regulated food-service operations.

Product Specifications

Overall dimensions 178 in. L × 32 in. F/B × 44 in. H (to top of backsplash)
Compartment size 24 in. L/R × 24 in. F/B × 12 in. D (each bowl)
Drainboard dimensions 36 in. L × 32 in. F/B (each side)
Backsplash height 8 in.
Material / gauge 16-ga. type 304 stainless steel
Base style Stainless open frame with adjustable side cross-bracing
Legs / feet (8) 1 5⁄8 in. O.D. legs with 1 in. adjustable bullet feet
Faucet centers 8 in. (two sets) *
Drain connection 1 ½ in. IPS (basket drains included)
Shipping weight Approx. 398 lb.

*This sink requires two deck-mount faucets. Faucets, pre-rinse units, cutting boards and other accessories are available separately.

Built-In Workflow Benefits

  • YES! It’s SeaMless!® construction reduces weld lines for faster clean-up and superior hygiene.
  • Large drainboards keep dirty and clean sides separate, helping you maintain health-code compliance.
  • Smart Fabrication™ program allows factory modifications to match unique kitchen layouts.
Installation note: Review the included rough-in drawings before running supply and waste lines. Follow all local plumbing codes. Additional support legs are factory-installed under each 36 in. drainboard for proper load distribution.

Upgrade your warewashing station with the capacity, durability and sanitary performance only an Advance Tabco Regaline sink can deliver.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Regaline

Certifications

NSF

Height

42.0in

Width

178.0in

Depth

32.0in

Shipping Weight

398.0lbs

Base Type

legs with side crossrails

Overall Length

130" - 198"

Top Gauge

16 gauge

Splash Height

8"

Base Construction

stainless steel

Sink Depth (rim - drain)

12"

Drainboards

with left & right-hand drainboards

Compartment (front - back)

24"

Top Stainless Series

300 series

Compartment Width (side - side)

24"

Specifications

Regaline Sink, 4-compartment, with left & right-hand drainboards, 24" front-to-back x 24"W sink compartments, 12" deep, with 8"H backsplash, stainless steel open frame base, side crossrails, 36" drainboards, 1" adjustable bullet feet, 16 gauge 304 stainless steel, overall 32" F/B x 178" L/R, NSF (requires 2 faucets)
