Advance Tabco Regaline 4-Compartment Sink with Left-Hand Drainboard, 24 x 24 x 12-Inch Bowls, 36-Inch Drainboard

SKU: 93-44-96-36L
GTIN: 747545108494
$6,657.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

4-compartment Sinks Advance Tabco Best Sellers Commercial Plumbing Supplies Commercial Sinks Compartment Sinks New Arrivals Restaurant Equipment Sinks & Handwashing Stations

Advance Tabco Regaline 4-Compartment Sink with Left-Hand Drainboard, 24 x 24 x 12-Inch Bowls, 36-Inch Drainboard

Standard 93 Series, 16-Gauge 304 Stainless Steel, 8-Inch Backsplash

Built for busy kitchens, this oversized 4-compartment sink combines deep 24-inch bowls, a left-hand drainboard, and rugged 304 stainless steel construction.

  • Four 24" x 24" compartments provide plenty of wash space for pots, pans, and dishware.
  • 12-inch-deep bowls help accommodate larger wash loads and reduce splash.
  • Left-hand 36-inch drainboard adds convenient landing and drying space.
  • 16-gauge 304 stainless steel construction is made for demanding commercial use.
  • 8-inch backsplash helps protect the wall behind the sink from splashes.
  • Open frame base with side crossrails and adjustable bullet feet supports stable installation.
  • Includes basket-type waste drains and is designed to accept two faucets.

Overall Dimensions:

146.0"W x 32.0"D x 42.0"H

Product Weight:

355.0 lb
Note: Conforms to NSF 61/9 lead free requirements. Notice for use or sale in California: Proposition 65 this faucet may expose you to chemicals, including lead, that are known to the State of California to cause cancer, or birth defects or other reproductive harm. For more information visit www.p65warnings.ca.gov.

Four Large Compartments

Four sink compartments measure 24 inches front-to-back by 24 inches side-to-side and are 12 inches deep.

Left-Hand Drainboard

A 36-inch drainboard is positioned on the left side for staging, draining, and air-drying items.

304 Stainless Steel Construction

Built with 16-gauge type 304 stainless steel for durability and corrosion resistance in commercial kitchens.

8-Inch Backsplash

The raised backsplash helps contain splashes and protect the wall surface behind the sink.

Open Frame Base

Stainless steel open frame base includes side crossrails for support and 1-inch adjustable bullet feet for leveling.

Plumbing-Ready Design

Faucet holes are spaced on 8-inch centers, waste drains are included, and two faucets are required.

Drainboard Support

Models with 36-inch drainboards are supplied with two additional legs per drainboard for added support.

TIG-Welded Satin Finish

Welded areas are blended to match adjacent surfaces and finished to a satin appearance.

Type 4-Compartment Sink
Style Regaline
Installation Type Floor Model
Compartments 4
Material 304 Stainless Steel
Finish Satin Finish
Top Gauge 16 Gauge
Base Type Legs With Side Crossrails
Drainboard Location Left-Hand
Drainboard Length 36 Inches
Compartment Width 24 Inches
Compartment Depth 24 Inches
Sink Depth 12 Inches
Backsplash Height 8 Inches
Water Inlet Size 1/2 Inch IPS
Drain Connection Size 1 1/2 Inch IPS
Water Connection Required
Drain Connection Required
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download PDF Installation manual PDF Download PDF Plumbing PDF Download

Frequently Asked Questions

No. The sink requires two faucets, but faucets are not included.
Each compartment measures 24 inches by 24 inches and is 12 inches deep.
This model has a left-hand drainboard.
It is made from 16-gauge type 304 stainless steel.
Yes. 1 1/2-inch IPS stainless steel basket-type waste drains are included.
