Advance Tabco  |  Regaline  |  SKU: 93-43-72-36L  |  UPC: 747545108425

Advance Tabco 93-43-72-36L Regaline Compartment Sinks

$5,578.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Plumbing Installation manual
Related Searches
Compartment Sinks Sinks & Handwashing Stations

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco Regaline 93-Series 3-Compartment Sink • 36" Left Drainboard

Model 93-43-72-36L | 16 ga Type 304 Stainless Steel | NSF

Engineered for high-volume warewashing, the Regaline 93-Series combines three spacious 24" × 24" bowls with an extra-long 36" drainboard—giving your dishroom the capacity and workflow it needs to stay ahead of the rush.

Why You’ll Love It

  • Heavy-duty 16 ga 304 stainless steel resists corrosion and everyday abuse.
  • Deep-drawn bowls with large 3" radius corners clean up fast and drain completely.
  • 12" water-level depth (16" flood level) meets the demands of pots, pans & sheet trays.
  • Integrated 8" backsplash with tile edge keeps water off the wall and speeds installation.
  • Oversized 36" left-hand drainboard with built-in splash and positive pitch.
  • TIG-welded seams ground smooth to a sanitary satin finish—Yes, it’s SeaMless!
  • Open tubular frame with adjustable side cross-bracing; extra pair of legs under the drainboard for added support.
  • (6) 1 5⁄8" Ø stainless steel legs with 1" adjustable bullet feet level the sink on uneven floors.
  • (3) 1 1⁄2" IPS basket drains centered in each bowl—strainers included.
  • Punched for two deck-mount faucets on 8" centers (faucets sold separately).
  • NSF listed for compliance with the latest food-safety standards.

Specifications

Overall length (L  ×  R) 120"
Overall depth (F  ×  B) 32"
Working height 34" to top of rolled rim (±1" via bullet feet)
Compartments 3
Bowl size 24" W × 24" F/B × 12" D (water level)
Drainboard 36" left-hand with 8" integrated splash
Backsplash height 8"
Material & thickness 16 ga Type 304 stainless steel
Legs / bracing (6) 1 5⁄8" Ø S/S legs • adjustable side cross-rails
Drains (3) 1 1⁄2" IPS basket drains (included)
Faucet holes (2) sets on 8" centers • 1 1⁄8" Ø
Certifications NSF
Faucets required but not included. This sink is punched for two 8"-on-center deck-mount faucets. Choose compatible NSF-approved faucets during checkout to complete your installation.

Need a custom size, pre-rinse, or additional drainboard? Ask about Advance Tabco Smart Fabrication™ for made-to-order solutions.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Regaline

Certifications

NSF

Height

42.0in

Width

120.0in

Depth

32.0in

Shipping Weight

339.0lbs

Drainboards

with left-hand drainboard

Compartment (front - back)

24"

Splash Height

8"

Top Stainless Series

300 series

Top Gauge

16 gauge

Base Type

legs with side crossrails

Compartment Width (side - side)

24"

Overall Length

109" - 170"

Sink Depth (rim - drain)

12"

Base Construction

stainless steel

Specifications

Regaline Sink, 3-compartment, with left-hand drainboard, 24" front-to-back x 24"W sink compartments, 12" deep, with 8"H backsplash, stainless steel open frame base, side crossrails, 36" drainboard, 1" adjustable bullet feet, 16 gauge 304 stainless steel, overall 32" F/B x 120" L/R, NSF (requires 2 faucets)
