Advance Tabco  |  Regaline  |  SKU: 93-4-72-24R  |  UPC: 747545108197

Advance Tabco 93-4-72-24R Regaline Compartment Sinks

$4,559.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco “Regaline” 4-Compartment Sink w/ 24" Right-Hand Drainboard

Standard Series • 93-4-72-24R • NSF Listed

Built for high-volume dishrooms, bar programs, and commissary kitchens, the Advance Tabco Regaline sink delivers rock-solid durability, smooth workflow, and effortless sanitation in one space-saving station.

At a Glance

  • Four 16" W x 20" F/B x 12" D deep-drawn bowls for multi-step washing & rinsing
  • 24" right-hand drainboard with splash — keeps cleanware safely above runoff
  • 16-gauge type 304 stainless steel top, bowls & backsplash (93 Series)
  • 8" high backsplash with tile edge for a snug, code-ready wall seal
  • Open stainless steel frame base with adjustable side crossrails for added rigidity
  • 1 5/8" Ø tubular stainless legs & heavy-duty 1" adjustable bullet feet
  • Large 3" interior corner radius promotes fast, thorough clean-ups
  • All TIG-welded construction; welds blended to a satin finish
  • NSF certified & SeaM Less® design for superior hygiene

Dimensions & Utilities

Overall size (W × L) 28" F/B × 102" L/R
Number of bowls 4
Individual bowl size 16" W × 20" F/B × 12" D
Drainboard 24" (right-hand) with integral splash
Backsplash height 8"
Drain connection 1 1/2" IPS stainless basket drains (included)
Faucet holes Two sets on 8" centers (faucets not included)
Material / gauge 16 ga 304 stainless (top & bowls) • 1 5/8" Ø legs
Feet 1" stainless bullet feet, height-adjustable
Certifications NSF

Why Choose Regaline?

  • Workflow efficiency — Four dedicated compartments streamline pre-wash, wash, rinse, and sanitize steps, helping you meet health-department requirements with ease.
  • Lasting value — 16-gauge 304 stainless offers higher nickel content and corrosion resistance than 400-series steel, so the sink won’t pit or rust in harsh chemical environments.
  • Labor-saving design — Seamless deep-drawn bowls, generous corner radii, and a one-piece rolled rim cut cleaning time and protect staff from sharp edges.
  • Field flexibility — Adjustable side cross-bracing lets you fine-tune stability around floor drains, while bullet feet level quickly on uneven surfaces.

Requires two deck-mount faucets with 8" centers (sold separately). Advance Tabco offers compatible swing-spout and gooseneck models along with cutting boards, sink covers, and scrap blocks to maximize prep space.

Installation note: Plumbing rough-ins should follow Advance Tabco’s recommended guidelines. Always verify local code compliance before setting equipment in place.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Regaline

Certifications

NSF

Height

42.0in

Width

102.0in

Depth

28.0in

Shipping Weight

186.0lbs

Sink Depth (rim - drain)

12"

Base Type

legs with side crossrails

Drainboards

with right-hand drainboard

Compartment (front - back)

20"

Compartment Width (side - side)

16"

Overall Length

98" - 113"

Splash Height

8"

Top Stainless Series

300 series

Base Construction

stainless steel

Top Gauge

16 gauge

Specifications

Regaline Sink, 4-compartment, with right-hand drainboard, 20" front-to-back x 16"W sink compartments, 12" deep, with 8"H backsplash, stainless steel open frame base, side crossrails, 24" drainboard, 1" adjustable bullet feet, 16 gauge 304 stainless steel, overall 28" F/B x 102" L/R, NSF (requires 2 faucets)
