Advance Tabco  |  Regaline  |  SKU: 93-22-40-18RL  |  UPC: 747545107688

Advance Tabco 93-22-40-18RL Regaline Compartment Sinks

$3,536.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco 93 Series “Regaline” 2-Compartment Sink with Dual 18" Drainboards

Model 93-22-40-18RL | NSF Listed

Built for busy commercial kitchens, the 93 Series Regaline sink combines rugged 16-gauge 304 stainless steel with Advance Tabco’s signature seamless construction. Two generous 20" × 20" bowls sit between full-size 18" left- and right-hand drainboards—giving you a dedicated wash-, rinse-, and air-dry workflow in one space-saving unit.

Key Features

  • Heavy-duty 16 ga. type 304 stainless steel – resists corrosion and stands up to daily abuse.
  • TIG-welded construction with satin-blended seams for a smooth, sanitary finish.
  • Deep-drawn, one-piece bowls with large 3" radius corners for easy cleaning.
  • Integral 18" drainboards on both sides with raised marine edge to contain spills.
  • 8" high tile-edge backsplash simplifies wall installation and keeps water off the floor.
  • Sturdy open-frame base with 1 5⁄8" O.D. tubular stainless steel legs and side cross-rails.
  • 1" adjustable stainless steel bullet feet ensure a level work surface.
  • (2) 1 ½" IPS stainless steel basket drains pre-installed in bowl centers.
  • Pre-punched 8" on-center faucet holes (faucets sold separately).
  • NSF certified for food-service sanitation.

At-a-Glance Specifications

Series / Gauge 93 Series – 16 ga. 304 SS
Compartments 2
Bowl Size (W × F/B × Depth) 20" × 20" × 12"
Drainboards 18" left & 18" right (integral, ribbed)
Overall Dimensions (L × F/B) 81" L × 28" F/B
Backsplash Height 8"
Drain Size 1 ½" IPS basket drains (included)
Legs / Feet 1 5⁄8" Ø SS legs with side cross-braces & 1" adjustable bullet feet
Faucet Holes (2) holes on 8" centers
Shipping Weight ≈ 147 lb
Certifications NSF

Need a different bowl configuration, cross-bracing, or special cutouts? Ask us about Advance Tabco Smart Fabrication™ custom modifications.

Important: Faucet(s), pre-rinse units, and P-traps are shown for reference only and are not included with this sink.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Regaline

Certifications

NSF

Height

42.0in

Width

81.0in

Depth

28.0in

Shipping Weight

147.0lbs

Compartment (front - back)

20"

Base Construction

stainless steel

Drainboards

with left & right-hand drainboards

Base Type

legs with side crossrails

Top Gauge

16 gauge

Compartment Width (side - side)

20"

Splash Height

8"

Overall Length

73" - 90"

Sink Depth (rim - drain)

12"

Top Stainless Series

300 series

Specifications

Regaline Sink, 2-compartment, with left & right-hand drainboards, 20" front-to-back x 20"W sink compartment, 12" deep, with 8"H backsplash, stainless steel open frame base, side crossrails, 18" drainboards, 1" adjustable feet, 16 gauge 304 stainless steel, overall 28" F/B x 81" L/R, NSF
