Advance Tabco 9-OPC-84DL Mop Sinks
Description
Advance Tabco Double-Width Mop Sink Cabinet – Left Sink
Model 9-OPC-84DL (18 ga 430 S/S Cabinet) • NSF ListedKeep your janitorial space organized, sanitary and ready for action with this all-in-one stainless steel cabinet and floor-mounted mop sink. Advance Tabco engineers every weld for durability and gives each surface a satin finish that looks sharp in any back-of-house or facility maintenance area.
Why You’ll Love It
- Space-saving 50 ⅜" wide footprint combines sink, shelving & mop-bucket bay in one cabinet.
- 16 ga 304 S/S sink bowl (20" W × 16" D × 12" H) resists corrosion and heavy daily use.
- 18 ga 304 S/S apron contains splashes and directs water back to the bowl.
- 18 ga 430 S/S cabinet body delivers durable storage at a value price.
- Four fixed shelves keep chemicals, towels and tools neatly organized (three on the right, one above the sink).
- Full-height opening on the right lets a standard mop bucket roll straight in—no lifting required.
- Two built-in mop holders keep handles upright, dry and easy to grab.
- Slotted side panels promote airflow, helping contents dry faster and reducing odors.
- Double hinged doors with magnetic catches provide quick, unobstructed access.
- Door is pre-punched & capped for an optional SU-27 security lock (sold separately).
- Factory-installed 2" IPS drain assembly included—just connect to your waste line.
- NSF listed for safe commercial use.
Specifications
| Overall Dimensions | 50 ⅜" W × 22 ¾" D × 84" H |
|---|---|
| Sink Location | Left side (floor level) |
| Sink Bowl Size | 20" W × 16" D × 12" H |
| Gauge / Material |
• Sink bowl: 16 ga 304 S/S • Sink apron: 18 ga 304 S/S • Cabinet: 18 ga 430 S/S |
| Shelves | 4 fixed (3 right, 1 left above sink) |
| Mop Holders | 2 (one on each side above sink) |
| Ventilation | Slotted panels on both end walls |
| Door Style | Double hinged, magnetic catch, lock-ready |
| Drain | 2" IPS brass & stainless assembly with strainer plate (included) |
| Compliance | NSF |
| Construction | All TIG welded; welds ground & polished to match satin finish |
Popular Add-Ons (Sold Separately)
- SU-27 Door Lock – secure chemicals and tools after hours.
- K-94-SHELF Extra fixed mid-shelf for 84" cabinets.
- K-94-BACK or K-94-BACK-300 Stainless steel back panel for freestanding installations.
- K-472 Service faucet holes (8" O.C.) factory-punched to your specified height.
- K-240 Service faucet.
Need a right-hand sink or full 300-series cabinet? Ask us about models 9-OPC-84DR, 9-OPC-84DL-300 and 9-OPC-84DR-300.
