Advance Tabco  |  Regaline  |  SKU: 9-84-80-36R  |  UPC: 747545107145

Advance Tabco 9-84-80-36R Regaline Compartment Sinks

$6,870.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco Regaline 4-Compartment Sink w/ 36" Right Drainboard

Model 9-84-80-36R | NSF Listed | 18 ga 304 Stainless Steel

Designed for high-volume dishrooms that demand durability, sanitation and efficient workflow, the Regaline 9-Series four-compartment sink pairs deep 20"-by-28" bowls with an extra-large 36" right-hand drainboard. All TIG-welded 18-gauge type 304 stainless steel and heavy-duty tubular legs ensure years of trouble-free service in the toughest commercial kitchens.

Key Features

  • Four one-piece deep-drawn bowls (20" W × 28" F/B × 12" D) with generous 3" radius corners for easy cleaning
  • Integral 8" backsplash with tile-edge for a sanitary, flush-to-wall installation
  • Extra-wide 36" drainboard (right side) with raised marine edge; supplied with two additional support legs
  • Open frame base with adjustable side cross-bracing for maximum rigidity and unobstructed floor access
  • 1 5/8" Ø stainless steel legs, stainless gussets and 1" adjustable bullet feet
  • Pre-punched 8"-on-center faucet holes – requires two faucets (sold separately)
  • (4) 1 1/2" IPS stainless steel basket drains included
  • Fully TIG welded; welds blended to a satin finish that matches adjacent surfaces
  • NSF certified for food-service sanitation compliance

At-a-Glance Specifications

Model 9-84-80-36R (Right-hand drainboard)
Compartments 4
Bowl Interior (W × F/B × D) 20" × 28" × 12"
Overall Dimensions (L × F/B) 130" × 36"
Backsplash Height 8" (with 1" return)
Drainboard Size 36" (right)
Material & Gauge 18 ga type 304 stainless steel
Legs / Bracing 1 5/8" Ø S/S tube legs, side cross-rails, 1" adjustable bullet feet
Faucet Holes (2) sets, 8" on center
Drain Size (4) 1 1/2" IPS drains with basket strainers
Approx. Shipping Weight ≈ 347 lb
Certifications NSF

Faucets, cutting boards, sink covers and other accessories are available separately. Advance Tabco may change specifications without notice.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Regaline

Certifications

NSF

Height

42.0in

Width

130.0in

Depth

36.0in

Shipping Weight

347.0lbs

Overall Length

130" - 198"

Compartment (front - back)

28"

Drainboards

with right-hand drainboard

Base Type

legs with side crossrails

Sink Depth (rim - drain)

12"

Top Stainless Series

300 series

Splash Height

8"

Top Gauge

18 gauge

Compartment Width (side - side)

20"

Base Construction

stainless steel

Specifications

Regaline Sink, 4-compartment, with right-hand drainboard, 28" front-to-back x 20"W sink compartments, 12" deep, with 8"H backsplash, stainless steel open frame base, side crossrails, 36" drainboard, 1" adjustable feet, 18 gauge 304 stainless steel, overall 36" F/B x 130" L/R NSF (requires 2 faucets)
