Advance Tabco  |  Regaline  |  SKU: 9-44-96-36RL  |  UPC: 747545106230

Advance Tabco 9-44-96-36RL Regaline Compartment Sinks

$6,909.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Installation manual Plumbing
Related Searches
Compartment Sinks Sinks & Handwashing Stations

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco “Regaline” 4-Compartment Sink with Dual 36" Drainboards

Model 9-44-96-36RL  |  18 ga. Type 304 Stainless Steel

Built for the busiest commercial kitchens, the Advance Tabco Regaline 4-compartment sink gives you generous washing capacity, rugged 18-gauge stainless-steel construction, and a pair of extra-long 36" drainboards for efficient prep and drying.

At a Glance
  • Four 24" F/B × 24" W × 12" D deep-drawn bowls with large 3" corner radius
  • Full-length 8" backsplash with 2 sets of 8"-on-center faucet holes (faucets required, sold separately)
  • Left- & right-hand 36" drainboards, each pitched for quick drainage and supplied with extra support legs
  • Open tubular frame with adjustable side cross-rails for rock-solid stability
  • 1 5⁄8"-dia. stainless-steel legs & 1" adjustable bullet feet level easily on uneven floors
  • All TIG-welded construction; welds blended to a smooth satin finish
  • NSF listed for food-service sanitation
Specifications
Overall size 32" F/B × 178" L/R (to rolled rim), 44" H to top of backsplash
Bowl size (4) 24" F/B × 24" W × 12" D
Drainboards 36" L (left) + 36" L (right) with integrally welded splash
Material / gauge 18 ga. type 304 stainless steel (sinks, tops & drainboards)
Backsplash height 8"
Drain openings 1 1⁄2" IPS stainless-steel basket drains (1 per bowl, included)
Required faucets Two deck-mounted faucets, 8" centers (not included)
Shipping weight (approx.) 382 lb

Dimensional tolerances: ±0.5" overall / ±0.25" interior. All data per manufacturer’s published specifications.

Plumbing & Installation
  • Supply lines: 1⁄2" IPS hot & cold
  • Waste: 1 1⁄2" IPS outlets, centered in each bowl
  • Leg clearance (front-to-rear): 20 1⁄8"
  • Ships knocked down; simple field assembly with included hardware
Freight notice: This oversized sink ships via common carrier. Lift-gate service, inside delivery, and other accessorials must be requested before shipment.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Regaline

Certifications

NSF

Height

42.0in

Width

178.0in

Depth

32.0in

Shipping Weight

382.0lbs

Drainboards

with left & right-hand drainboards

Overall Length

130" - 198"

Base Type

legs with side crossrails

Splash Height

8"

Top Stainless Series

300 series

Sink Depth (rim - drain)

12"

Top Gauge

18 gauge

Compartment (front - back)

24"

Base Construction

stainless steel

Compartment Width (side - side)

24"

Specifications

Regaline Sink, 4-compartment, with left & right-hand drainboards, 24" front-to-back x 24"W sink compartments, 12" deep, with 8"H backsplash, stainless steel open frame base, side crossrails, 36" drainboards, 1" adjustable bullet feet, 18 gauge 304 stainless steel, overall 32" F/B x 178" L/R, NSF (requires 2 faucets)
