Advance Tabco  |  Regaline  |  SKU: 9-42-48  |  UPC: 747545106032

Advance Tabco 9-42-48 Regaline Compartment Sinks

$2,897.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Installation manual Plumbing
Related Searches
Compartment Sinks Sinks & Handwashing Stations

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco Regaline 2-Compartment Sink — 62" L x 32" W

Model 9-42-48 | 24" x 24" x 12" Bowls | NSF Listed

Engineered for demanding commercial kitchens, the Regaline two-compartment sink combines extra-deep 24" square bowls with heavy-duty 18-gauge 304 stainless steel construction. The open-frame base, 8" backsplash and adjustable bullet feet make installation fast and cleaning effortless—so you can stay focused on service, not maintenance.

Key features
  • (2) 24" front-to-back x 24" wide x 12" deep deep-drawn bowls with easy-clean 3" radius corners.
  • 18-gauge type 304 stainless steel resists rust, chemicals and food acids.
  • 8" high backsplash with tile edge and pre-punched 8" on-center faucet holes (faucet sold separately).
  • Open stainless steel frame with 1 5/8" O.D. legs, welded gussets and side cross-rails for maximum rigidity.
  • (2) 1 1/2" IPS stainless steel basket drains furnished and centrally located in each bowl.
  • 1" adjustable stainless steel bullet feet level the sink on uneven floors.
  • All TIG-welded seams blended to a uniform satin finish.
  • NSF certified for food-service sanitation.
Specifications
Compartments 2
Bowl size (L x W x D) 24" x 24" x 12"
Overall dimensions (L x W) 62" left-to-right x 32" front-to-back
Backsplash height 8"
Material / gauge 304 stainless steel, 18 ga
Legs 1 5/8" O.D. tubular stainless steel w/ side cross-rails
Feet 1" adjustable stainless steel bullet feet
Drain size & qty. (2) 1 1/2" IPS basket drains (included)
Faucet holes 8" centers (faucet not included)
Approx. shipping weight 133 lb.
Certification NSF
Ideal for
  • Restaurant pot-washing stations
  • Bakery and commissary prep areas
  • Catering and ghost-kitchen dish rooms
  • School, hospital & institutional kitchens
Note: Faucet, shut-off valves and final plumbing connections are not included; install to local code.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Regaline

Certifications

NSF

Height

42.0in

Width

62.0in

Depth

32.0in

Shipping Weight

133.0lbs

Compartment (front - back)

24"

Drainboards

without drainboards

Base Type

legs with side crossrails

Overall Length

54" - 62"

Base Construction

stainless steel

Splash Height

8"

Sink Depth (rim - drain)

12"

Compartment Width (side - side)

24"

Top Gauge

18 gauge

Top Stainless Series

300 series

Specifications

Regaline Sink, 2-compartment, 24" front-to-back x 24" wide sink compartments, 12" deep, with 8" high splash, stainless steel open frame base, side crossrails, 1" adjustable bullet feet, 18 gauge 304 stainless steel, overall 32" F/B x 62" L/R, NSF
