Advance Tabco 9-42-48-36RL Regaline Compartment Sinks
Description
Advance Tabco “Regaline” 2-Compartment Sink
with Dual 36" Drainboards
Model 9-42-48-36RL | NSF Listed
Built for high-volume kitchens that demand durability and workflow efficiency, this Regaline sink pairs two generous 24" × 24" bowls with extra-long drainboards on both the left and right. The 18-gauge, type 304 stainless construction is fully TIG-welded, delivering the rugged performance you expect from Advance Tabco.
Top Features
- Two 24" × 24" × 12" deep, deep-drawn bowls with large 3" radius corners for easy cleaning.
- 36" drainboards on both sides speed up prep and drying; each drainboard is factory-supplied with two extra support legs.
- 8" high backsplash with 1" tile edge helps contain splashes and simplifies wall installation.
- 18-gauge 304 series stainless steel—corrosion-resistant, food-safe, and easy to sanitize.
- Open-frame base with 1 5/8" Ø tubular stainless legs, adjustable side crossrails, and 1" bullet feet for a rock-solid, level work station.
- TIG-welded seams ground and polished to a satin finish.
- Pre-punched 8" on-center faucet holes (fixtures sold separately).
- Includes (2) 1 ½" IPS stainless basket drains.
At-a-Glance Specs
| Overall dimensions | 125" L × 32" D * × 44" H ** |
|---|---|
| Compartments | 2 |
| Bowl size (each) | 24" W × 24" F/B × 12" D (14" flood level) |
| Drainboards | 36" left & 36" right (reinforced with 4 additional legs) |
| Backsplash | 8" H with 1" tile edge & rolled rim |
| Material / gauge | 18-ga type 304 stainless steel |
| Legs & bracing | 1 5/8" Ø tubular 304 SS legs, adjustable side crossrails, stainless gussets |
| Feet | 1" adjustable stainless bullet feet |
| Faucet holes | (2) holes on 8" centers (faucet not included) |
| Drain openings | (2) 1 ½" IPS, basket strainers included |
| Shipping weight | Approx. 314 lb |
| Certifications | NSF |
* Front-to-back dimension measured to backsplash.
** 34" working height to rolled rim; 44" to top of backsplash. All dimensions are typical and subject to standard ±½" tolerances.
Why Choose a Regaline Sink?
- Made in the USA by Advance Tabco—industry leader in commercial fabrication.
- Engineered leg clearance ensures unobstructed under-sink access for plumbing and storage.
- Compatible with Poly-Vance cutting boards, sink covers, and a wide range of smart accessories to further streamline your line.
- Fully field-weldable for seamless integration into custom counter runs.
Image(s) may show a similar Regaline configuration for illustrative purposes.
