Advance Tabco 9-24-80-36R Regaline Compartment Sinks
Description
Advance Tabco Regaline 4-Compartment Sink with 36" Right-Hand Drainboard
Model 9-24-80-36R • 130"W × 28"D • 18-Gauge 304 Stainless SteelBuilt for demanding back-of-house workflows, the Regaline Super Saver 9-Series sink combines seamless TIG-welded construction with the everyday value of 18-gauge type 304 stainless steel. Four spacious 20" × 20" × 12" bowls tackle prep, pot and ware-washing tasks while a full 36" right-hand drainboard keeps dirty and clean items organized and moving.
Key Advantages
- All 18-ga. type 304 stainless steel top, bowls, backsplash & drainboard for superior corrosion resistance.
- (4) Deep-drawn 12"-deep sink compartments with 3" coved corners for fast, hygienic clean-up.
- 8" high backsplash with tile edge protects walls and installs flush.
- 36" integral drainboard slopes toward bowls; two additional legs add rock-solid support.
- Open frame base with 1 5⁄8" Ø tubular stainless legs, gussets & adjustable side cross-rails.
- 1" adjustable stainless bullet feet level the unit on uneven floors.
- NSF listed for food-service sanitation.
Perfect For
- High-volume dish & pot stations
- Hotels, schools & healthcare kitchens
- Commissary, ghost-kitchen & catering production areas
Technical Specifications
| Model | 9-24-80-36R (right drainboard) |
|---|---|
| Compartments | 4 |
| Bowl inside size (W × F/B × Depth) | 20" × 20" × 12" |
| Drainboard | 36" long, right side |
| Backsplash | 8" high with 2" return |
| Overall dimensions | 130"W × 28"D |
| Material thickness | 18-ga. type 304 stainless steel |
| Base & legs | (6) 1 5⁄8" Ø S/S legs, side cross-bracing, 1" bullet feet |
| Drains | (4) 1-1/2" IPS stainless basket drains (included) |
| Faucet holes | (2) sets on 8" centers – faucets not included |
| Shipping weight | Approx. 250 lb |
| Certifications | NSF |
Plumbing & Installation Notes
- Hot & cold water supply: 1/2" IPS.
- Waste outlet: 1-1/2" IPS, centered in each bowl.
- Requires two deck- or wall-mount faucets on 8" centers (sold separately).
- Front-to-rear leg clearance: 16 1/8" • Right-to-left leg clearance: 91 1/8".
Need help choosing faucets, pre-rinse sprayers or sink covers? Contact our food-service team for expert recommendations.
