Advance Tabco  |  Regaline  |  SKU: 9-24-80-24RL  |  UPC: 747545105721

Advance Tabco 9-24-80-24RL Regaline Compartment Sinks

$4,977.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Installation manual Plumbing
Related Searches
Compartment Sinks Sinks & Handwashing Stations

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco Regaline 4-Compartment Sink w/ Dual 24" Drainboards

Super Saver Series • Model 9-24-80-24RL • NSF Certified

Built for high-volume dish and pot washing, the Regaline 9-Series delivers rugged all-stainless performance in a space-saving footprint. Four roomy 20" × 20" bowls, integrated 24" drainboards on both ends, and an open frame base with adjustable side cross-rails make this sink a dependable workhorse for restaurants, catering kitchens, commissaries and more.

Key Features
  • Four deep-drawn bowls – 20" × 20" × 12" (L × W × D) with generous 3" corner radius for easy cleaning
  • Dual 24" drainboards (left & right) with stamped drainboard splash for fast drying & staging
  • 18 ga. type 304 stainless steel top, bowls & drainboards – corrosion-resistant and food-safe
  • 8" high backsplash with tile-edge for flush wall installation
  • Open stainless steel frame base with 1⅝" O.D. tubular legs, gussets & adjustable side cross-bracing
  • 1" stainless steel bullet feet adjust for uneven floors
  • Pre-punched 8" on-center faucet holes (two faucets required – sold separately)
  • (4) 1½" IPS basket drains included & centrally located
  • NSF listed – meets strict sanitation standards
Technical Specifications
Overall dimensions 138" L × 28" D × (37" H to rim / 45" H to top of backsplash)*
Bowl size (4) 20" L × 20" W × 12" D
Drainboard size 24" L (each end) with drainboard splash
Material / gauge Type 304 stainless steel, 18 gauge top & bowls
Backsplash height 8" with 2" return at 45°
Plumbing connections Faucet holes: ½" IPS, 8" on-center (two sets)
Waste: 1½" IPS basket strainer drains (included)
Shipping weight Approx. 275 lb

*34" working height can be lowered or raised approximately 1" via bullet feet.

Ideal Applications
  • High-volume dish & glass washing
  • Pot & pan clean-up stations
  • School, hospital & commissary kitchens
  • Food-truck or ghost-kitchen prep areas (where space permits)
Important: Two 8"-center splash-mount faucets are required and sold separately. Compatible Advance Tabco swing-spout and pre-rinse faucets are available – see “Faucets & Accessories”.

Need a custom modification, extra legs, or sink covers? Advance Tabco’s Smart Fabrication™ team can help – contact us for details.

Features & Specs

Manufacturer

Advance Tabco

Brand_name

Regaline

Certifications

NSF

Height

42.0in

Width

138.0in

Depth

28.0in

Shipping Weight

275.0lbs

Overall Length

130" - 198"

Compartment (front - back)

20"

Splash Height

8"

Base Type

legs with side crossrails

Sink Depth (rim - drain)

12"

Drainboards

with left & right-hand drainboards

Compartment Width (side - side)

20"

Top Gauge

18 gauge

Top Stainless Series

300 series

Base Construction

stainless steel

Specifications

Regaline Sink, 4-compartment, with left & right-hand drainboards, 20" front-to-back x 20"W sink compartments, 12" deep, with 8"H backsplash, stainless steel open frame base, side crossrails, 24" drainboards, 1" adjustable bullet feet, 18 gauge 304 stainless steel, overall 28" F/B x 138" L/R, NSF (requires 2 faucets)
