Advance Tabco 9-22-40 Regaline Compartment Sinks
$2,186.00
Unit price
/
Unavailable
Description
Regaline 2-Compartment Stainless Steel Sink – 20" x 20" Bowls
Advance Tabco Super Saver 9-Series • Model 9-22-40Built for busy prep, dish and pot washing stations, the Advance Tabco Regaline 9-22-40 delivers commercial-grade durability in a compact 54" footprint. Two spacious 20" square bowls are deep-drawn from seamless 18 ga. type 304 stainless steel for superior sanitation and long service life.
Key Features
- (2) 20" F/B x 20" L/R compartments, 12" water depth (16" flood level).
- 8" high rear backsplash with 1" tile edge contains splashes and simplifies installation.
- 18 ga. 304 stainless steel bowls with large 3" radius corners for easy cleaning.
- Open frame base with 1 5/8"-diameter stainless steel legs.
- Adjustable side cross-rails with leg clamps add rigidity while keeping the front open for storage or floor cleaning.
- (2) 1 ½" IPS stainless steel basket drains located in the center of each bowl (included).
- Pre-punched 8" center faucet holes (faucets sold separately).
- NSF listed; all TIG-welded seams blended to a satin finish.
Specifications
| Series / Model | Regaline Super Saver 9 Series – 9-22-40 |
|---|---|
| Number of Compartments | 2 |
| Bowl Dimensions (each) | 20" front-to-back × 20" left-to-right × 12" deep |
| Overall Dimensions | 28" front-to-back × 54" left-to-right |
| Backsplash Height | 8" |
| Material / Gauge | 18 ga. type 304 stainless steel |
| Legs & Feet | 1 5/8" Ø tubular stainless legs with stainless steel adjustable bullet feet |
| Cross-Bracing | Adjustable side rails, open front & back |
| Faucet Mounting | (2) 1 ¹⁄₈" dia. holes on 8" centers |
| Drain Size / Type | 1 ½" IPS basket drains (included) |
| Approx. Shipping Weight | 79 lb. |
Recommended Accessories (sold separately)
- 8"-center wall-mount or deck-mount faucets
- Remote P-trap & plumbing kits
- Poly-Vance cutting boards & sink covers
- 18", 24" or 36" add-on drainboards
Heads up: Faucet, supply lines and trap are shown for illustration only and are not included with the sink.
Features & Specs
Features & Specs
Manufacturer
Advance Tabco
Brand_name
Regaline
Height
42.0in
Width
54.0in
Depth
28.0in
Shipping Weight
79.0lbs
Base Construction
stainless steel
Splash Height
8"
Base Type
legs with side crossrails
Drainboards
without drainboards
Compartment Width (side - side)
20"
Compartment (front - back)
20"
Sink Depth (rim - drain)
12"
Top Gauge
18 gauge
Top Stainless Series
300 series
Specifications
Regaline Sink, 2-compartment, 20" front-to-back x 20" W compartment, 12" deep, with 8" high splash, stainless steel open frame base, side crossrails, 18 gauge 304 stainless steel, overall 28" F/B x 54" L/R
