Advance Tabco  |  SKU: 19-FM-80-ADA  |  UPC: 747545217684

Advance Tabco 19-FM-80-ADA Hand Sinks

$2,823.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Installation & operation
Related Searches
Hand Sinks Sinks & Handwashing Stations

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Advance Tabco 80" Multi-Station ADA Hand Sink

Model 19-FM-80-ADA • 4 Users • Faucets Not Included

Built for the busiest food-service, educational and industrial environments, this free-standing Advance Tabco sink lets four people wash at once while meeting all current ADA knee-clearance requirements. Heavy-gauge 304 stainless steel, rugged tubular legs and a generous backsplash deliver years of worry-free sanitation.

Key Features
  • 4-station design speeds up hand-washing during peak times.
  • ADA compliant 5" deep bowl and 34" rim height for wheelchair accessibility.
  • 16 ga. type 304 stainless steel with TIG-welded square corners and satin finish.
  • 8 ½" backsplash factory-punched with four 8" O.C. faucet hole sets (faucets sold separately).
  • Includes one K-6 3 ½" rear basket drain for efficient waste handling.
  • 1 5/8" O.D. tubular stainless steel legs with flanged feet and adjustable side/rear cross-bracing.
  • Stainless steel “Z” wall bracket for additional support and code-compliant installation.
  • NSF certified for open food-zone use.
Why You’ll Love It
  • Saves space: one footprint serves four users.
  • Simplifies cleaning: open base allows easy floor access under the sink.
  • Field-adjustable bracing guarantees rock-solid stability even on uneven floors.
  • Corrosion-resistant stainless steel extends service life in wet or chemical environments.
Specifications
Overall Width 80" (2032 mm)
Overall Depth 19 ½" (495 mm)
Overall Height 42 ½" (1080 mm) to top of backsplash
Bowl Size (each station) 16" front-to-back × 5" deep
Backsplash Height 8 ½"
Faucet Holes 4 sets, 8" on-center, 1 ¼" dia.
Faucets not included.
Drain (1) 3 ½" K-6 rear basket drain
Material 16 ga. type 304 stainless steel
Legs / Feet 1 5/8" O.D. tubular SS legs, flanged feet
User Stations 4
Weight ≈ 100 lb (45 kg)
Compliance NSF • ADA • RoHS
Installation Notes
  • Mount supplied “Z” bracket 42 ½" above finished floor to top of bracket.
  • Centerline of drain: 6 ¼" below finished floor. Water supplies: 5" above floor.
  • Anchor flanged feet to floor per local code (anchors not provided).
  • Verify faucet selection meets ADA reach and activation requirements.
Prop 65 Notice: Adding faucets or other plumbing components may expose you to chemicals, including lead, known to the State of California to cause cancer or birth defects. For more information visit www.P65Warnings.ca.gov.

Advance Tabco continually improves products; specifications are subject to change without notice. Always consult the included installation manual for the latest instructions.

Features & Specs

Manufacturer

Advance Tabco

Certifications

ADA Compliant

Height

42.5in

Width

80.0in

Depth

19.5in

Shipping Weight

102.0lbs

Bowl Depth (front to back)

15" - 19" front-to-back

Bowl Height (rim to drain)

5" deep

Style

freestanding

Faucet

faucet not included

Features

multi-station

Specifications

Multiwash Hand Sink, with stainless steel legs and flanged feet, 80"W x 19-1/2"D x 42-1/2"H (overall), 16" front-to-back x 5" deep (bowl size), 8-1/2"H backsplash, punched with (4) sets of faucet holes 8" OC, includes 3-1/2" rear basket drain, 16 gauge 304 stainless steel construction, ADA compliant
