AccuTemp E34403E120 DBL Evolution Steamers (Countertop & Floor)
Description
Evolution™ Double-Stack Boilerless Convection Steamer
Model E3 (Connected) • 12 kW • 440 V / 60 Hz / 3-Phase • Includes StandGive your high-volume kitchen the speed of steam without the headaches of a boiler. The AccuTemp Evolution™ double-stack steamer harnesses patented Steam Vector Technology to cook faster, save water, and deliver pan-to-pan consistency—all while eliminating costly filtration and de-liming forever.
Why You’ll Love It
- Boiler-Free Steam Vector Technology – no moving parts, no exposed element, no scheduled maintenance.
- Lightning-Fast Throughput – two independent 3-pan cavities (6 pans total) keep up with the rush.
- Water Miser – uses less than 1.5 gal (5.7 L) per hour—up to 90 % less than traditional steamers.
- Totally Filter-Free – warranty is never voided by water quality and no filter cartridges to change.
- Simple Digital Controls – one-touch Cook or Variable-Hold modes plus independent 99-min timers with presets.
- Chef-Friendly Door – heavy-duty, field-reversible and can be opened anytime during the cycle.
- Built-in Safety – low-water, high-water & over-temp lights with auto shut-off protection.
- Made in the USA, ENERGY STAR®, cULus & UL EPH Classified.
Pan Capacity (per cavity)
- 3 × 12 in × 20 in × 2.5 in (65 mm) pans (6 pans total in double-stack)
- OR 2 × 12 in × 20 in × 4 in pans
Technical Specifications
| Heat Input | 12 kW total (6 kW per cavity) |
|---|---|
| Electrical | (2) 5 ft cords, NEMA L16-20P, 440 V / 60 Hz / 3-ph, 20 A circuit per cavity |
| Water Connection | 3⁄4 in MGH; plumb cold potable line |
| Drain Connection | 3⁄4 in barbed; separate line required for each cavity |
| Water Consumption | < 1.5 gal (5.7 L) per hour |
| Cavity Construction | Reinforced 14-ga 304 stainless steel |
| Controls | Digital temperature display, independent programmable timers, Cook & Variable-Hold modes |
| Overall Dimensions* | W 27.9 in × D 23.6 in × H 55.4 in (on stand) |
| Certifications | ENERGY STAR®, cULus, UL EPH, EPA 202 / NFPA 96 4.1.1.2 |
| Warranty | 1-Year parts & labor + Lifetime Service & Support Guarantee |
*Refer to spec sheet for detailed clearances and utility locations.
What’s Included
- Factory-installed stacking kit & stainless steel stand (casters, bullet or flanged feet—choose at time of order)
- (2) dishwasher-safe wire pan racks & front condensate tray
- Front-mounted drain valve & water shut-off
- Installation/operation manual
Popular Add-Ons
- Perforated cooking shelves
- Bullet feet kit (instead of casters)
AccuTemp® products may be covered by one or more U.S. patents. See AccuTempIP.net for details.
