Key specifications

Type
Water Filter
Style
Valve-In-Head
Capacity
719 Gallons @ 9 gpg
Service Flow Rate
1 GPM
Application
Espresso Machines
Reduction Claims
Hardness, Sediment, Chlorine Taste And Odor
Spec sheet
3M Purification SKU: SGP165BN-T GTIN: 05900422037637

3M Purification SGP165BN-T Espresso Machine Water Filter, Hardness Reduction, 1 GPM, 719-Gallon Capacity, Valve-in-Head

$300.11
/each
Estimated to ship in 16–19 business days
Treatment
Flow rate
Replacement Cartridges
Included: 3M Purification warranty Five-year limited warranty on the product and one-year limited warranty on the disposable filter cartridge

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $28/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Water Filter
Style Valve-In-Head
Capacity 719 Gallons @ 9 gpg
Service Flow Rate 1 GPM
Application Espresso Machines
Reduction Claims Hardness, Sediment, Chlorine Taste And Odor
Filter Media Carbon Block And Ion Exchange
Connection Size 3/8 Inch FNPT
Maximum Operating Pressure 125 psi
Maximum Operating Temperature 100°F
Bypass Ratio 25% Untreated
Cartridge Change 1/4 Turn
Units Per Case 1

Description

The SGP165BN-T is a single-cartridge water filtration system for espresso and espresso-based drinks. It provides hardness, sediment, and chlorine taste and odor reduction at flow rates up to 1.0 GPM.

The system includes a valve-in-head design, an integral mounting bracket, and a Sanitary Quick Change encapsulated cartridge connection for cartridge changes with a one-quarter turn.

  • Rated capacity: 719 gallons at 9 gpg hardness
  • Connections: 3/8-inch FNPT horizontal inlet and outlet ports
  • Operating limits: 125 psi maximum pressure and 100°F maximum temperature

Overall Dimensions:

4.5"W x 5.5"D x 16.5"H

Product Weight:

6.1 lb

Hardness Reduction

Weak acid ion-exchange resin reduces calcium and magnesium ions to help reduce hard scale formation on heating coils and boilers.

Chlorine Taste And Odor Reduction

Activated carbon reduces chlorine taste and odor and associated bitterness.

Sediment Reduction

Sediment reduction is included among the authoritative reduction claims for this system.

Valve-In-Head Design

The valve-in-head design simultaneously shuts off and vents water for cartridge changes without shutting off the upstream feed water.

Sanitary Quick Change Cartridge

The encapsulated cartridge design supports cartridge changes with a one-quarter turn without contact with the filter media.

Built-In Bypass

The bypass directs 75% of inlet water through the media and allows 25% to pass through untreated.

Integral Mounting Bracket

The system includes a head assembly with an integral mounting bracket.

Horizontal Inlet And Outlet Ports

The system has 3/8-inch FNPT horizontal inlet and outlet plumbing connections.

Frequently Asked Questions

The system is rated for 719 gallons with inlet water at 9 gpg hardness, equivalent to 150 ppm.
The authoritative reduction claims are hardness, sediment, and chlorine taste and odor.
The recommended service flow rate is up to 1.0 GPM.
It uses 3/8-inch FNPT horizontal inlet and outlet ports.
Yes. The valve-in-head design simultaneously shuts off and vents water during cartridge changes.
The maximum operating pressure is 125 psi and the maximum operating temperature is 100°F.
The cartridge should be replaced every 12 months, at rated capacity, or when a noticeable reduction in flow rate occurs.
