3M Purification ICE190-S Ice Maker Water Filter System, 0.2 Micron, 5 GPM, 54,000-Gallon Capacity
The 3M™ ICE190-S is a single-vessel water filter system for commercial ice applications. It provides a 0.2-micron rating, up to 5 GPM flow, and 54,000-gallon capacity.
The system includes a shut-off valve, pressure gauge, integral mounting bracket, and single o-ring seal cartridge filter. Its filtration claims include cyst, bacteria, sediment, chlorine taste and odor, and scale reduction, with built-in scale inhibition.
- 1/2-inch FNPT inlet and outlet connections
- Maximum operating pressure of 125 psi
- Maximum operating water temperature of 100°F
- Sanitary Quick Change cartridge design
Overall Dimensions:
8.0"W x 5.5"D x 23.63"HProduct Weight:
6.25 lbIce application filtration
Designed for commercial ice applications, including ice cubers and flakers.
Reduction claims
The system is specified for cyst, bacteria, sediment, chlorine taste and odor, and scale reduction.
Scale inhibition
Built-in scale inhibition reduces the ability of calcium and magnesium to precipitate on evaporator plates as hard scale.
Sanitary cartridge change-out
The encapsulated cartridge design supports cartridge change-outs without contact with the filter media.
Integrated system components
Includes a head assembly with pressure gauge, inlet water shut-off valve assembly, integral mounting bracket, and a single cartridge filter.
Plumbing connections
Uses 1/2-inch FNPT horizontal inlet and outlet ports.
Operating limits
Maximum operating pressure is 125 psi and maximum operating water temperature is 100°F.
Certifications & Compliance
Warranty & Protection
The ICE190-S system is warranted against defects in material and workmanship for five years from the date of purchase. The disposable filter cartridge is warranted for one year from the date of purchase.
