Wells (Middleby)  |  SKU: WG-3036-NAT

Wells (Middleby) WG-3036-NAT Gas Griddles

$9,194.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Gas Griddles Griddles & Flat Tops

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Wells WG-3036G Countertop Gas Griddle – 35-7/8" x 24" Smooth Plate, 75,000 BTU, Natural Gas

Heavy-duty thermostatic griddle for high-volume kitchens

Built for speed, consistency and easy cleanup, the Wells WG-3036G delivers 75,000 BTU/hr of evenly distributed heat across a generous 6 sq ft cooking surface. Three independent snap-action thermostats let you sear steaks on one end while holding pancakes on the other, all on a 3/4" thick polished steel plate that recovers heat fast and lasts for years.

Key Features
  • 3/4" smooth polished steel griddle plate for superior heat retention & easy seasoning
  • Three U-shaped burners with internal baffling ensure edge-to-edge temperature uniformity
  • Zoned snap-action thermostats (one every 12") for precise 200–450 °F control
  • Stainless steel body, splashguard and hinged front panel protect vital components
  • Full-width 3-1/2" grease trough plus 4-qt removable front drawer simplify cleanup
  • Adjustable air shutters on each burner optimize combustion for maximum efficiency
  • 3/4" NPT rear gas connection, natural gas, 75,000 BTU/hr total output
  • Meets NSF/ANSI 4 & CSA standards; cETLus listed for safety
  • Backed by a 1-year parts & labor warranty from Wells Manufacturing
Chef-Ready Capacity

Keep up with the rush without sacrificing quality.

Menu Item Per Load Per Hour*
Hamburgers (4 oz.) 73 1,095
Steaks (10 oz.) 26 310
Pancakes (4" Ø) 60 720
Eggs 79 1,106

*Production figures are approximate and assume continuous loading.

Specifications
Model WG-3036G
Gas Type Natural
Total BTU 75,000 BTU/hr (3 × 25,000)
Cooking Surface (W × D) 35-7/8"  ×  24"
Overall Dimensions (W × D) 35-3/4"  ×  30"
Plate Thickness 3/4"
Thermostat Zones 3 (one every 12")
Gas Connection 3/4" NPT (rear)
Required Clearances Back 3"  |  Sides 3"  |  Bottom 4"
Shipping Weight 305 lb / 138 kg
What’s Included
  • Integrated 1-1/2" rear & side splashguard
  • 4-qt front-mount grease drawer
  • 4" adjustable stainless steel legs
  • Owner’s/installation manual
Installation Note: This griddle must be installed and connected by a licensed technician in accordance with local gas codes.

Need a grooved or chrome-plated surface? Special-order plates are available—contact us for details.

Features & Specs

Manufacturer

Wells (Middleby)

Certifications

NSF, CSA

Height

12.38in

Width

35.81in

Depth

30.0in

Shipping Weight

325.0lbs

Cooking Surface Width (side - side)

31" - 36"

Cooking Surface Depth (front - back)

24" - 29"

Griddle Plate Finish

smooth steel

Exterior Finish

all stainless steel exterior

Controls

thermostat / solid state controls

Plate Thickness

3/4"

Specifications

Griddle, countertop, natural gas, 35-7/8" W x 24" D cooking surface, smooth polished steel griddle plate, zoned thermostatic heat control, stainless steel construction, with splashguard, 75,000 BTU/HR, CSA, NSF 4
