Wells (Middleby)  |  SKU: WG-2424-NAT

Wells (Middleby) WG-2424-NAT Gas Griddles

$5,868.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Gas Griddles Griddles & Flat Tops

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Wells WG-2424G Countertop Gas Griddle – 24"

Natural Gas | 50,000 BTU | Smooth Steel Plate

Compact footprint, big-griddle performance. The Wells WG-2424G delivers the high-output searing, browning and toasting you need in a busy diner, concession stand or satellite kitchen—all from the top of your worktable.

Key Features

  • 3/4" thick polished steel cooking plate maximizes heat retention and recovery.
  • Two 25,000 BTU U-shaped burners distribute heat evenly across the entire surface.
  • Snap-action thermostats (one every 12") create two independent temperature zones.
  • Stainless steel hinged front panel protects control knobs from damage and splatter.
  • Full-width grease trough feeds a 4-qt removable drawer for quick, mess-free clean-up.
  • Integrated rear & side splashguard keeps surrounding stations clean.
  • Adjustable air shutters on each burner optimize combustion and fuel economy.
  • Heavy-duty stainless steel exterior—built for the demands of commercial kitchens.
  • Field convertible to LP gas with optional kit (sold separately).

Specifications

Cooking surface 23 7/8" W × 20 1/2" D (≈ 490 in²)
Plate thickness 3/4" smooth polished steel
Total heat input 50,000 BTU/hr (2 × 25,000 BTU burners)
Controls 2 snap-action thermostats (dual zones)
Temperature range Approx. 200 °F – 450 °F (93 °C – 232 °C)
Gas connection 3/4" NPT (rear), natural gas, 5" W.C. manifold
Overall dimensions 23 3/4" W × 25 3/8" D × 11 1/2" H (with splashguard)
Shipping weight 190 lb
Certifications CSA, NSF/ANSI Std. 4
Warranty 1-year parts & labor

Typical Hourly Output*

Product Per Load Per Hour
Hamburgers, 4 oz 37 ≈ 555
Steaks, 8 oz 14 ≈ 160
Pancakes, 4" dia. 30 ≈ 360
Eggs 40 ≈ 560

*Figures provided by Wells Manufacturing. Actual results will vary with recipe, temperature and operator technique.

Optional Upgrades

  • Chrome-plated griddle surface for easier release and faster clean-up.
  • Grooved 3/4" steel plate for classic char-marks on proteins.
  • LP gas conversion kit.
Installation note: Maintain minimum clearances of 3" at the back and sides and 4" below the unit to the nearest combustible surface. Professional installation is strongly recommended to ensure safe operation and to preserve warranty coverage.

Need guidance? Our equipment specialists are ready to help you size, spec and ship your new Wells griddle.

Features & Specs

Manufacturer

Wells (Middleby)

Certifications

NSF, CSA

Height

12.38in

Width

23.81in

Depth

25.38in

Shipping Weight

210.0lbs

Exterior Finish

all stainless steel exterior

Cooking Surface Depth (front - back)

20" - 23"

Griddle Plate Finish

smooth steel

Cooking Surface Width (side - side)

19" - 24"

Plate Thickness

3/4"

Controls

thermostat / solid state controls

Specifications

Griddle, countertop, natural gas, 23-7/8" W x 20-1/2" D cooking surface, smooth polished steel griddle plate, zoned thermostatic heat control, stainless steel construction, with splashguard, 50,000 BTU/HR, CSA, NSF 4
