Wells (Middleby) HDG-2430G Gas Griddles
Description
Wells HDG2430G 24" Heavy-Duty Gas Countertop Griddle
Middleby Essentials • Quick Ship – Leaves our warehouse within 5 business daysBuilt for bustling diners, cafés, and food-truck lines, the Wells HDG2430G delivers serious power and consistency in a compact 24-inch footprint. Two individually controlled 30,000 BTU burners heat a ¾-inch thick steel plate, giving you rapid pre-heat, even temperatures, and lightning-fast recovery batch after batch.
Key Features
- 24" W × 23-9/16" D cooking surface (3.8 sq ft) handles burgers, breakfast, and sear work with ease.
- ¾" polished steel griddle plate retains heat for consistent browning and reduced temperature swings.
- Dual manual controls with infinite adjustment put responsive heat at the operator’s fingertips.
- Adjustable air shutters on each burner fine-tune combustion for optimum efficiency and flame quality.
- Factory-set for Natural Gas; LP conversion kit included for on-site flexibility.
- One-piece stainless splashguard plus stainless front & sides stand up to daily commercial abuse.
- Full-width grease trough channels runoff into an extra-large, front-removable drip pan.
- 4" adjustable heavy-duty steel legs steady the unit and make cleanup underneath a breeze.
- NSF listed and cULus certified for sanitation and safety compliance.
- Backed by a 1-year parts & labor warranty and Middleby’s nationwide service network.
Technical Specifications
| Model | HDG2430G |
|---|---|
| Controls | 2 manual, infinite adjustment |
| Total BTU | 60,000 BTU/hr (2 × 30,000) |
| Gas Connection | ¾" NPT rear |
| Gas Type | Natural Gas 5" W.C. Field convertible to LP (10" W.C.) – kit included |
| Plate Thickness | ¾" (19 mm) steel |
| Usable Cooking Area | 24" W × 23-9/16" D (610 × 598 mm) |
| Overall Dimensions | 24-1/8" W × 31-11/16" D × 17" H (with 4" legs) |
| Clearances (Non-Combustible) | Back & Sides: 0" • Front: 0" • Bottom: 4" |
| Shipping / Installed Weight | 249 lb / 199 lb (113 kg / 90 kg) |
| Certifications | NSF, cULus |
Built for High-Volume Kitchens
- Heavy-duty construction pairs perfectly with Wells HD series hotplates and charbroilers for a seamless cookline.
- Fast recovery keeps up with rushes, reducing ticket times and increasing throughput.
- Quick-ship availability gets you grilling in as little as one week.
Looking for thermostatic controls or a larger size? Check out the full HDG/HDTG series for even more configurations.
