Pitco Solstice Supreme™ Reduced-Oil-Volume Fryer System — 3-Fryer Gas Battery
1 × 32 lb Full Pot • 2 × 17 lb Split-Pot Fryers • Built-In Filter Drawer • Auto Top-Off ControlsCut oil use by up to 40 % without sacrificing throughput. The Solstice Supreme™ battery delivers five independent fry zones, lightning-fast filtration and rock-steady product consistency — all in less than 63 inches of line space.
Key Benefits
- Reduced-oil design: full pot cooks like a 50 lb fryer while holding only 32 lb of oil.
- Four 17 lb split pots let you run separate items without flavour transfer.
- FILTER SOON production monitor tells staff exactly when to filter.
- Two-step Solstice™ filter drawer cycle — filter and re-heat in under 5 minutes.
- Push-button Auto Top-Off dilutes oxidised oil and maintains perfect cooking depth.
- Blower-free atmospheric burners are quieter, simpler and easier to maintain.
- Heavy-duty stainless steel tank, front, doors and sides withstand daily abuse.
- ENERGY STAR® qualified full-pot model delivers lower utility bills.
Intellifry™ Smart Controls
- Stores up to 12 cook programs per pot for menu consistency.
- Audible timers, lock-outs and cook-count tracking protect product quality.
- Records oil hours, filter cycles and usage data for easier oil-life management.
Integrated Solstice™ Filter Drawer
- 4.5 GPM pump and 10 × 20.5 in. filter envelope handle high-volume filtering all day.
- 3 in. clog-free drain with swivel spout virtually eliminates splashing.
- On-board 35 lb Jug-In-Box storage with low-jug indicator eliminates carrying hot oil through the kitchen.
What’s in the Box
- (1) SSHLV14 full-pot fryer — 32 lb oil, 72,500 BTU
- (2) SSHLV14T split-pot fryers — each side 17 lb oil, 37,000 BTU
- Built-in filter drawer with pan, lid, starter filter pack and scoop
- Intellifry computers with push-button oil top-off
- 9 in. adjustable legs, drain clean-out rod and tank cleaning brush
Certifications
- CSA Flame & CSA Star
- NSF
- CE
- ENERGY STAR® (SSHLV14 frypot)
Technical Specifications
| Model / Pot | Oil Capacity | Frying Area | Gas Input |
|---|---|---|---|
| SSHLV14 — Full Pot | 32 lb (15.6 L) | 13 × 13.6 in. | 72,500 BTU/hr |
| SSHLV14T — Split Pot (per side) | 17 lb (8.25 L) | 6.9 × 13.6 in. | 37,000 BTU/hr |
| Fryers / Zones | 3 cabinets / 5 independent fry zones | ||
| Total Gas Input | ≈ 217,000 BTU/hr | ||
| Filtration Pump | 1/3 HP | 4.5 GPM | ||
| Dimensions (W × D × H) | 62.2 × 31 × 46.8 in. (158.0 × 78.8 × 118.9 cm) | ||
| Utilities | Gas — 3⁄4 in. NPT rear manifold | Electric — 115 V, 60 Hz, 0.7 A (controllers) + 6.7 A (filter pump) | ||
Dimensions and utilities are for reference only and may vary with options. Verify with the factory drawings before installation.
Peace-of-Mind Warranty
1 -year parts & labour, plus a 10-year fry-tank warranty as standard from Pitco.
Installation Note: This equipment must be installed under a commercial exhaust hood and connected to the specified gas and electrical services by a qualified technician. Correct installation is required to keep the warranty in force.
Need Financing?
Spread the cost over affordable monthly payments with Middleby Equipment Financing. Ask your account manager for details.
Pitco Frialator (Middleby)
Pitco Frialator (Middleby) SSHLV14C/14T-2/FD Solstice Supreme Gas Fryers
SKU: SSHLV14C/14T-2/FD
$70,832.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Pitco Solstice Supreme gas fryer system: reduced oil volume, computerized controls, built-in filter drawer, stainless steel, high BTU output.
Manufacturer
Pitco Frialator (Middleby)
Brand name
Solstice Supreme
Certifications
NSF, CE, CSA Star, CSA Flame
Height
45.75in
Width
46.88in
Depth
30.0in
Fat Capacity (approximate)
(1) 30 & (4) 15 lb
Filter
built-in filter
Exterior Finish
all stainless steel exterior
With or without basket lifts
without basket(s)
Fryer Quantity
(3) tanks
Fry pot
stainless steel
Controls
computer controls
Specifications
Solstice Supreme™ Reduced Oil Volume Fryer System, gas, (3) fryers, (1) 32 lb. oil capacity full tank & (4) 17 lb. oil capacity twin tanks, computer controls with push button top off, built-in Solstice™ Filter Drawer System, fresh oil jug holder with low jug indicator, stainless steel tank, front, door & sides, (1) 72,500 BTU, (4) 37,000 BTU, CSA Flame, CSA Star, NSF, CE
