Pitco Frialator (Middleby) 40D Gas Fryers
Pitco Frialator (Middleby) 40D Gas Fryers is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Description
Pitco 40D Tube-Fired Gas Fryer — 40-45 lb Capacity (Quick Ship)
Mid-volume floor fryer with 107,000 BTU of dependable powerServe up crispy, consistent results shift after shift with the Pitco 40D. This tube-fired gas fryer pairs a rugged stainless-steel tank with simple millivolt controls—no electrical hookup required—making it the perfect solution for kitchens that demand performance in a compact footprint.
Key Benefits
- 40–45 lb oil capacity handles medium-volume production without constant top-offs.
- 200°F–400°F (93°C–204°C) thermostat for precise, repeatable frying.
- 107,000 BTU tube burners with high-temperature alloy baffles for rapid heat recovery.
- Deep 20 % cool zone protects oil by trapping sediment below the heat tubes.
- Millivolt control & standing pilot—runs anywhere, even without electricity.
- Temperature-limit shut-off and integrated gas valve for built-in safety.
- Front 1 ¼" full-port drain plus drain extension & clean-out rod streamline filtering.
- Stainless-steel tank, front & door; galvanized sides & back for durability and easy cleaning.
- 6" adjustable legs for perfect leveling; optional casters available.
- Quick Ship—usually departs the warehouse within 24–48 hours.
What’s Included
- (2) Nickel-plated oblong/twin wire mesh baskets
- (1) Nickel-plated tube rack
- (1) Drain line clean-out rod
- (1) Drain extension
- Removable basket hanger & integral flue deflector
Technical Specifications
| Model | Pitco 40D |
|---|---|
| Oil Capacity | 40–45 lb (18–20 kg) |
| Frying Area | 14" × 14" (356 × 356 mm) |
| Cook Depth | 4"–6" (102–152 mm) |
| Heat Input | 107,000 BTU/hr (31.4 kW) |
| Gas Connection | ¾" NPT — Natural 4" W.C. / LP 10" W.C. |
| Drain Connection | 1 ¼" NPT front full-port valve |
| Overall Dimensions | 15 ⅛" W × 30 ¹³⁄₃₂" D × 47 ⁹⁄₃₂" H (384 × 769 × 1 201 mm) |
| Shipping Weight | ≈ 181 lb (82 kg) |
| Certifications | CSA Flame, CSA Star, NSF |
| Warranty | 1-Year parts & labor + 10-Year fry tank (limited) |
Ideal For
Diners, food trucks, concession stands, ghost kitchens, and any operation that needs reliable medium-volume frying without sacrificing floor space.
Looking for a fryer battery or optional casters? Contact us—most accessories ship just as fast as your new fryer.
