Lang LG Series 72" Electric Heavy-Duty Countertop Griddle
Model 172T • 6 Independent Zones • 36 kW Total OutputBuilt for high-volume diners, hotels, and institutional kitchens, the LG Series combines marathon durability with precise zone control. Six snap-action thermostats and a full-inch steel plate give you the muscle to handle breakfast rushes, sizzling lunch specials, and everything in between—without sacrificing consistency.
Key Advantages
- Expansive 72" W × 23" D cooking surface delivers nearly 11.5 ft² of production area.
- 1" (25 mm) polished steel plate retains heat for rapid recovery and uniform browning.
- Accu-Temp™ snap-action thermostats—one per 12" section—maintain 200-550 °F.
- 6 kW incoloy-sheathed element under each zone (36 kW total) for steakhouse-level searing.
- Welded steel frame with stainless exterior stands up to daily commercial abuse.
- 5" tapered wrap-around splash guard keeps grease where it belongs.
- 8 qt. front-mounted grease drawer + 1" trough for fast, mess-free cleanup.
- 4" adjustable stainless legs (1-5/8" range) ensure a level working height on any counter.
- NSF listed & proudly Made in the USA.
Precision Performance
- Embedded probes react instantly to surface temp swings, holding ±15 °F of set point.
- Individually control pancakes, burgers, and sauté items side-by-side without flavor transfer.
- Optional Selectronic™ solid-state controls (±4 °F accuracy) and chrome or grooved plates available—ask for details.
Specifications
| Cooking surface | 72" W × 23" D (1830 mm × 584 mm) |
|---|---|
| Plate thickness / material | 1" polished steel |
| Heat zones | 6 (one every 12") |
| Temperature range | 200 °F – 550 °F (93 °C – 288 °C) |
| Element rating | 6 kW per zone • 36 kW total (two 18 kW banks) |
| Electrical | 208 V or 240 V, 1- or 3-phase (field convertible) 480 V / 3-phase available Requires two hard-wire connections |
| Grease management | 8 qt (7.6 L) stainless drawer & 1" trough |
| Splash guard | 5" tapered, wrap-around |
| Overall size (H × D × W) | 18.8" × 28.5" × 72" |
| Shipping weight | ≈ 787 lb. (357 kg) |
| Certifications | NSF, cETLus |
| Origin | Smithville, Tennessee, USA |
What’s Included
- Factory-installed 4" adjustable legs
- Stainless 8 qt. grease drawer
- Owner’s manual and warranty registration
Warranty
Lang backs the LG Series with a 2-year parts & labor warranty—delivering peace of mind right alongside legendary performance.
Need a custom plate finish, clamshell hood, or equipment stand? Contact our team via the request form for a tailored quote.
