Lang Manufacturing (Middleby) 172T LG Series Electric Griddles
Lang Manufacturing (Middleby) 172T LG Series Electric Griddles is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Lang Manufacturing (Middleby) 172T LG Series Electric Griddles
Description
Lang LG Series 72" Electric Heavy-Duty Countertop Griddle
Model 172T • 6 Independent Zones • 36 kW Total OutputBuilt for high-volume diners, hotels, and institutional kitchens, the LG Series combines marathon durability with precise zone control. Six snap-action thermostats and a full-inch steel plate give you the muscle to handle breakfast rushes, sizzling lunch specials, and everything in between—without sacrificing consistency.
Key Advantages
- Expansive 72" W × 23" D cooking surface delivers nearly 11.5 ft² of production area.
- 1" (25 mm) polished steel plate retains heat for rapid recovery and uniform browning.
- Accu-Temp™ snap-action thermostats—one per 12" section—maintain 200-550 °F.
- 6 kW incoloy-sheathed element under each zone (36 kW total) for steakhouse-level searing.
- Welded steel frame with stainless exterior stands up to daily commercial abuse.
- 5" tapered wrap-around splash guard keeps grease where it belongs.
- 8 qt. front-mounted grease drawer + 1" trough for fast, mess-free cleanup.
- 4" adjustable stainless legs (1-5/8" range) ensure a level working height on any counter.
- NSF listed & proudly Made in the USA.
Precision Performance
- Embedded probes react instantly to surface temp swings, holding ±15 °F of set point.
- Individually control pancakes, burgers, and sauté items side-by-side without flavor transfer.
- Optional Selectronic™ solid-state controls (±4 °F accuracy) and chrome or grooved plates available—ask for details.
Specifications
| Cooking surface | 72" W × 23" D (1830 mm × 584 mm) |
|---|---|
| Plate thickness / material | 1" polished steel |
| Heat zones | 6 (one every 12") |
| Temperature range | 200 °F – 550 °F (93 °C – 288 °C) |
| Element rating | 6 kW per zone • 36 kW total (two 18 kW banks) |
| Electrical | 208 V or 240 V, 1- or 3-phase (field convertible) 480 V / 3-phase available Requires two hard-wire connections |
| Grease management | 8 qt (7.6 L) stainless drawer & 1" trough |
| Splash guard | 5" tapered, wrap-around |
| Overall size (H × D × W) | 18.8" × 28.5" × 72" |
| Shipping weight | ≈ 787 lb. (357 kg) |
| Certifications | NSF, cETLus |
| Origin | Smithville, Tennessee, USA |
What’s Included
- Factory-installed 4" adjustable legs
- Stainless 8 qt. grease drawer
- Owner’s manual and warranty registration
Warranty
Lang backs the LG Series with a 2-year parts & labor warranty—delivering peace of mind right alongside legendary performance.
Need a custom plate finish, clamshell hood, or equipment stand? Contact our team via the request form for a tailored quote.
