Imperial (Middleby) IHR-G18-1HT Spec Series Gas Ranges
Description
Spec Series 36" Heavy-Duty Gas Range
Model IHR-G18-1HT • 18" Griddle + 18" Hot Top • Standard Oven • 120,000 BTUBuilt for demanding commercial kitchens, the Imperial Spec Series IHR-G18-1HT combines a mirror-polished griddle, an even-heat hot top and a chef-depth oven in one 36" footprint. Heavy-gauge stainless construction, 120,000 BTU of total power and thoughtful details—like a 4" grease trough with 1-gallon can—deliver the speed, consistency and durability chefs expect from Imperial.
Cooking Surfaces
- 18" Griddle Top – Highly polished steel plate for uniform searing; 30,000 BTU “U” burner promotes even heat and fast recovery.
- 18" Even-Heat Hot Top – Two heavy-duty polished plates (18" × 28") with 40,000 BTU “U” burner; ideal for stockpots, sauté pans and holding.
- Individual manual gas valves and standing pilots for precise surface control.
- 4" (102 mm) wide stainless grease gutter routes runoff to a 1-gallon (3.8 L) can for quick, mess-free disposal.
Standard Oven Performance
- 40,000 BTU oven burner with 100 % safety pilot & manual shut-off.
- Unique baffle design distributes heat evenly throughout the 26 ½" W × 26" D × 14" H cavity.
- Chef-depth interior accepts full-size (18" × 26") sheet pans left-to-right or front-to-back.
- Porcelainized sides, deck, rear and door liner for easy wipe-down cleaning.
- Heavy-duty door hinge & “cool-zone” side-mounted controls.
- One chrome oven rack included; additional racks optional.
Durable Construction & Ergonomics
- All stainless steel front, sides, 5" landing ledge, backguard & kick plate.
- Sleek radius edges and welded, polished seams for a professional look.
- Cast-aluminum control knobs with heat-shield grip stay cool to the touch.
- 6" (152 mm) heavy-duty legs with adjustable feet for easy leveling.
- 3/4" rear gas connection simplifies single-unit hook-up.
Specifications
| Gas type | Natural or Propane (specify) |
|---|---|
| Total input | 120,000 BTU/hr • 35 kW |
| Griddle plate | 18" W × 28" D polished steel, 30,000 BTU “U” burner |
| Hot top | 18" W × 28" D plates, 40,000 BTU “U” burner |
| Oven burner | 40,000 BTU/hr |
| Oven interior (WxDxH) | 26 ½" × 26" × 14" (673 × 660 × 356 mm) |
| Overall dimensions (WxDxH) | 36" × 38" × 36" to cooktop (914 × 965 × 914 mm) |
| Shipping weight | 765 lb (347 kg) |
| Gas connection | 3/4" NPT, rear |
| Certifications | cETLus, NSF |
| Warranty | 1-year parts & labor |
Popular Options & Accessories
- Stainless steel high shelf or double overshelf
- Modular salamander / cheese-melter mounts
- Extra chrome oven racks
- 6" (152 mm) casters in place of legs
- Quick-disconnect or flexible gas hose kits
Imperial warrants this range to be free from defects in materials and workmanship for one (1) year on parts and labor. See full warranty for terms, exclusions and service details.
