Imperial (Middleby) IHR-6-XB Spec Series Gas Ranges
Description
Imperial Spec Series 36″ Heavy-Duty Gas Range – 6 Open Burners, Cabinet Base (Model IHR-6-XB)
Harness 240,000 BTU of cooking power and keep vital cookware right at your fingertips. The Imperial IHR-6-XB combines six high-performance open burners with an open stainless-steel storage base, making it the perfect workhorse for demanding restaurants, hotels and institutional kitchens.
Why chefs choose the IHR-6-XB
- Six 40,000 BTU burners deliver instant, responsive heat with a 7,000 BTU low-simmer feature for delicate sauces.
- Rugged cast-iron “S” grates (12″ × 14″ each) form a continuous, level surface for safe pan movement.
- Anti-clogging burner design and removable grates simplify daily cleaning.
- 5″ (127 mm) deep stainless landing ledge—plenty of room for plating and oversize stockpots.
- Full stainless-steel exterior (front, sides, 9-½″ backguard & kick plate) with welded, polished seams.
- Open cabinet base with bottom shelf keeps sheet pans, stock pots or smallwares close at hand.
- Extra-large, removable crumb tray under the burners speeds end-of-shift clean-up.
- Durable cast-aluminum control knobs feature a heat-protective grip for operator comfort.
- 6″ (152 mm) heavy-duty legs with adjustable feet ensure rock-solid stability on uneven floors.
Engineered for performance
- One-piece venturi base—no gaskets—slopes toward the burner for more efficient combustion.
- All stainless-steel tubing plus solid-brass burner components stand up to years of high-heat use.
- Enclosed front 1-¼″ (32 mm) manifold keeps the cookline looking clean and professional.
- Factory-ready for natural gas; easily field-convertible to LP with optional kit.
Technical specifications
| Model | IHR-6-XB |
|---|---|
| Burners / Type | 6 open; cast-iron, anti-clog |
| Total Input | 240,000 BTU / 70 kW (40,000 BTU per burner) |
| Cooking Surface | (6) grates, 12″ × 14″ (305 × 356 mm) each |
| Dimensions (W × D × H) | 36″ × 38″ × 36″ (914 × 965 × 914 mm) to cooktop Backguard adds 9-½″ (241 mm) height |
| Landing Ledge Depth | 5″ (127 mm) |
| Gas Connection | ¾″ NPT, rear; manifold pressure 5.0″ W.C. (NG) / 10.0″ W.C. (LP) |
| Clearances | 0″ sides & rear from non-combustible surfaces; 8″ (203 mm) from combustibles |
| Shipping Weight | 575 lb (261 kg) |
| Certifications | cETLus, NSF |
| Warranty | One-year limited parts & labor |
Popular options (sold separately)
- 6″ (152 mm) swivel casters with front locks
- Common plate shelves, high shelves & plate rails for a seamless, continuous cookline
- Flanged feet for curb mounting
- LP conversion kit
Compliance & peace of mind
- Meets NSF sanitation standards for open-top ranges.
- cETLus listed for both U.S. and Canada.
- Backed by Imperial’s one-year parts & labor warranty when installed by an authorized tech.
Installation must conform to local codes. For safe operation, provide adequate ventilation and verify gas type before hookup.
