Imperial (Middleby) IFSSP450 Gas Fryers
Description
Imperial IFSSP450 4-Battery 50 lb Tube-Fired Gas Fryer w/ Space-Saver Filter System
560,000 BTU • 5.5 GPM Roller Pump • Snap-Action ThermostatsTackle peak-hour demands while extending oil life with the Imperial IFSSP450. This all-in-one, four-fryer battery delivers the fire-power of 560,000 BTU and houses its own high-speed filtration system beneath the cabinet—freeing up valuable floor space and keeping operations running fast, clean, and safe.
Performance & Convenience
- Space-saver under-fryer filtration eliminates the need for a separate filter cart.
- 5.5 GPM, 1/3 HP roller pump completes a filter cycle quickly and can push oil up to 20 ft for disposal.
- Four independent 50 lb stainless steel frypots supply a combined 560,000 BTU of even, tube-fired heat.
- Responsive snap-action thermostats (200–400 °F) recover temperature fast for consistent results.
- Positive-latching filter paper holder and quick-disconnect return hose keep filtration fast and mess-free.
- Continuous stainless steel cabinet with 5" front landing ledge looks sharp and wipes clean in seconds.
- Factory-installed casters, joiner strips, and filter starter kit included—roll in, hook up, and fry.
- Single-point rear gas manifold simplifies installation; certified CSA Flame & Star, NSF, CE.
Built to Save
- Save Space: Integrated filter keeps aisles clear and the footprint compact.
- Save Oil: Frequent, effortless filtration improves food quality and extends oil life.
- Save Time: Filter all four fryers in one seamless cycle—no wheeling equipment around.
Technical Specifications
| Model | IFSSP450 |
|---|---|
| Oil Capacity | 4 × 50 lb frypots (200 lb total) |
| Total BTU Input | 560,000 BTU/hr |
| Heat Source | Tube-fired, gas (natural or LP – specify) |
| Thermostat | Snap-Action, 200–400 °F |
| Filter Pump | 5.5 GPM roller pump, 1/3 HP motor |
| Filter Electrical | 120 V / 60 Hz / 1-ph, 6.8 A (6 ft cord & 3-prong plug) |
| Gas Connection | ¾" rear manifold, single point |
| Overall Dimensions | 62" W × 35" D × 45 ¾" H |
| Shipping Weight | ≈ 1,062 lb |
| Construction | Stainless steel frypots, front & sides; welded cabinet |
| Mobility | 4 heavy-duty casters (front locking) |
| Certifications | CSA Flame, CSA Star, NSF, CE |
| Warranty | 1-year parts & labor; 5-year pro-rated frypot |
Clearance: 0" to non-combustible surfaces, 6" to combustible surfaces. Legs or casters required on non-combustible floors. Optional accessories—basket lifts, gas shut-off valve, tank covers, and more—sold separately.
