Imperial IFSCB275E Dual-Battery Electric Fryer with Side-Car Filter System
75 lb Oil Capacity per Frypot • Built-In Dump & Warming Station • Immersed ElementsEngineered for high-volume kitchens that refuse to compromise on speed, consistency or floor space, the Imperial IFSCB275E combines two full-size 75 lb electric fryers with an integrated, under-cabinet filtration system and side-car dump station. From chicken wings to fries, you’ll enjoy rapid recovery, cleaner oil and a streamlined workflow—all in one, continuous stainless-steel battery that rolls wherever you need it.
Performance & Efficiency
- Immersed, swing-up heating elements transfer heat directly to the oil for fast recovery and lower energy cost.
- 75 lb (51 L) capacity per frypot—150 lb total—to keep up with peak-hour demand.
- Snap-action thermostat provides precise temperature control and quick response to load changes.
- 5.5 GPM roller pump (1/3 HP) filters a full frypot in minutes and can discharge oil to a disposal vat up to 20 ft away.
Integrated Side-Car Filter System
- Filter pan, drain lines and return lines are internally plumbed—no external hoses to manage.
- Positive-latching filter paper holder and quick-disconnect return line ensure mess-free operation.
- Stainless-steel filter pan is easy to remove and clean.
- Includes filter starter kit so you can begin filtering on day one.
Dump & Warming Station
- Matching stainless cabinet with heated food warmer keeps finished product at serving temperature.
- Full-size dump pan and sloped drain area speed up seasoning and salting.
- Cabinet can be positioned anywhere within the fryer battery for the ideal workflow.
Durability & Mobility
- Seam-welded stainless-steel frypots, front and sides resist corrosion and simplify clean-up.
- Continuous 5" (127 mm) landing ledge for safe loading and staging.
- Heavy-duty casters and joiner strips (included) create a rock-solid, moveable battery.
Specifications
| Model | IFSCB275E (Immersed Elements) |
|---|---|
| Number of Fryers | 2 |
| Oil Capacity | 75 lb (51 L) per frypot | 150 lb total |
| Cabinet Width | 58-1/2" (1486 mm) |
| Depth × Height | 40-1/2" D × 44-1/8" H (1029 mm × 1121 mm) |
| Shipping Weight | 720 lb (327 kg) |
| Electrical – Per Fryer* |
208 V / 3 ph / 60 Hz – 50.02 A 240 V / 3 ph / 60 Hz – 43.35 A 480 V / 3 ph / 60 Hz – 21.68 A |
| Electrical – Filter Pump | 115 V / 1 ph / 6.8 A |
| Pump Capacity | 5.5 GPM (1/3 HP roller pump) |
| Thermostat | Mechanical snap-action |
| Certifications | cETLus, CSA Flame, CSA Star, CSA-Sanitation, CE |
| Clearances | 0" sides & back (non-combustible); 6" (152 mm) combustible surfaces |
| Included Accessories | Food warmer, dump pan, joiner strips, filter starter kit, casters |
*Electrical data shown per fryer. Two fryers plus filter system require separate connections as listed.
Warranty
• 1-year parts & labor on the entire unit
• 5-year pro-rated warranty on the stainless-steel frypots
Installation Note: This appliance is designed for use on non-combustible floors with legs or casters installed.
Always follow local electrical & fire codes and the Imperial installation manual.
$35,767.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Imperial IFSCB275E electric floor fryer: dual 75 lb frypots, built-in filter, dump station, 5.5 GPM pump, stainless steel, casters, NSF/CSA certified.
Manufacturer
Imperial (Middleby)
Certifications
CE, cETLus, CSA-Sanitation, CSA Star, CSA Flame
Height
44.13in
Width
58.5in
Depth
40.5in
Shipping Weight
720.0lbs
With or without basket lifts
without basket(s)
Fat Capacity (approximate)
75 lbs each
Fryer Quantity
(2) tanks
Fry pot
stainless steel
Controls
thermostatic controls
Filter
built-in filter
Exterior Finish
all stainless steel exterior
Specifications
Fryer, electric, floor model, (2) battery, 75 lb. capacity each, immersed elements, built-in filter system, dump station, 5.5 GPM roller pump, snap action thermostat, includes: food warmer, dump pan, joiner strips & filter starter kit, stainless steel frypot, front & sides, casters, 1/3 HP, cETLus, CSA Flame, CSA Star, CSA-Sanitation, CE
