Garland UTOG36-SU6 US Range UT Counter Hot Plates
Description
Garland US Range UTOG36-SU6 36" Heavy-Duty Step-Up Gas Hot Plate
Six 30,000 BTU Open Burners • Countertop • CSA & NSF CertifiedBoost your line’s throughput without expanding its footprint. The Garland US Range UTOG36-SU6 packs a full 180,000 BTU/h into a rugged, two-tier hot plate that lets you work multiple pans front-to-back for maximum volume and lightning-fast ticket times.
Key Features
- (6) 30,000 BTU/h Performer Pro two-piece octagonal burners – three front, three raised rear
- Individual manual gas valves with continuous pilot lights for instant ignition
- Split, ergonomic cast-iron grates lift off for effortless cleaning and protect pilots from spills
- Heavy-gauge stainless steel front, sides & back plus a full-width stainless crumb tray
- 4" (102 mm) stainless steel adjustable legs for reliable, level installation
- 4"-deep front rail with 3 1/2" work surface for safe, comfortable pan handling
- Factory-installed 3/4" NPT regulator and “T” manifold for straight-through or flush rear gas hook-up
- Required clearances: 7" (178 mm) sides • 6" (152 mm) rear to combustibles
- Commercial approvals: CSA Gas, CSA Sanitation, NSF
Built for High-Volume Kitchens
The step-up configuration creates two levels of intense heat, so you can keep sauté pans roaring up front while larger stockpots simmer on the elevated rear row—all within easy reach and without reaching over active flames.
Specifications
| Model | UTOG36-SU6 |
|---|---|
| Burners | (6) open top — 30,000 BTU/h each |
| Total Input | Natural Gas: 180,000 BTU/h • Propane Gas: 156,000 BTU/h |
| Gas Connection | 3/4" NPT rear (regulator included) |
| Width | 35 7/16" (900 mm) |
| Depth | 32" (814 mm) |
| Height | 19 13/16" (503 mm) with 4" legs |
| Shipping Weight | 191 lb (87 kg) |
| Operating Pressure | Natural: 7" WC (17.5 mbar) • Propane: 11" WC (27.5 mbar) |
Optional accessories include stainless steel stands (stationary or mobile), countertop skirts, and condiment rails. Ask our team for a tailored quote.
