Garland U60-6G24SS US Range U Series Ranges Gas Ranges
Description
U-Series 60" Gas Restaurant Range – 6 Open Burners & 24" Griddle
Garland / U.S. Range • Model U60-6G24SSBuilt for non-stop, high-volume production, the Garland U-Series 60" range combines six 32,000 BTU open burners with a spacious 24" smooth-steel griddle and dual storage bases— giving chefs the power, flexibility and on-hand storage they need in one rock-solid station.
- Six 32,000 BTU 2-piece cast-iron open burners with ergonomic split-grates for fast, even heat.
- Right-hand 24" W × 23" D × 5/8" thick smooth steel griddle plate with manual Hi/Lo valve control.
- Two full-width open storage bases (in lieu of ovens) keep sheet pans, pots and smallwares within reach.
- Expansive 27" deep work-top and a 5" stainless steel plate rail for safe plating and staging.
- Durable stainless steel front, sides, 2-piece backguard & shelf for easy cleaning and long service life.
- Individual 12" stamped drip trays with dimpled bottoms slide out for quick clean-up.
- 6" adjustable stainless steel legs level the unit on uneven floors; flanged-deck or caster kits available.
- Factory-installed 3/4" NPT gas regulator and large, heavy-duty control knobs.
- Certified CSA Flame • CSA Star • cCSAus • NSF for commercial use across North America.
| Overall width | 59-1/16" (1500 mm) |
|---|---|
| Overall depth | 34-1/2" (876 mm) • Work-top depth 27" (686 mm) |
| Overall height | 57" (1448 mm) with standard backguard & shelf |
| Burners | 6 × 32,000 BTU open top • 2 × 18,000 BTU griddle “H” burners |
| Total input |
228,000 BTU/hr Natural Gas (Propane: 186,000 BTU/hr) |
| Griddle surface | 24" W × 23" D × 5/8" thick smooth steel, manual control |
| Bases | Left & right open storage compartments (no ovens) |
| Gas connection | 3/4" NPT rear, supplied with regulator |
| Manifold pressure | Natural 4.5" WC • Propane 10" WC |
| Shipping weight | ≈ 646 lb (293 kg) • Volume 79 cu ft |
- Snap-action modulating griddle thermostat (175 – 425 °F)
- 12" hot-top plate (18,000 BTU) in lieu of two open burners
- Low-profile 9-3/8" backguard
- 6" locking swivel casters (set of 4)
- Flanged deck-mount legs
- Piezo spark ignition for griddle pilots
For commercial use only. Installations above 2,000 ft (610 m) may require derating—consult your local gas authority. Ranges supplied with casters must be secured with an approved restraining device.
