Garland U-Series 60" Gas Restaurant Range – 4 Burners & 36" Griddle, Dual Storage Base
Model U60-4G36SS | 182,000 BTU Total InputGive your line cooks the power of four 32,000 BTU open burners plus a full 36" manual-control griddle, all without sacrificing valuable storage. Built from the ground up for demanding commercial kitchens, this Garland/US Range U-Series unit delivers unbeatable versatility, rugged stainless-steel construction and industry-leading efficiency in a single 60" footprint.
Highlights
- 4 × 32,000 BTU open top burners with split ergonomic cast-iron grates for fast, even heating.
- 36" × 23" smooth steel griddle plate, 5/8" (15 mm) thick for excellent heat retention and recovery.
- Manual hi/lo valves and three 18,000 BTU cast-iron “H” style griddle burners provide zoned temperature control.
- Two full-width open storage bases keep cookware and sheet pans close at hand (no ovens to heat or maintain).
- 27" (686 mm) deep work surface with 5" (127 mm) stainless plate rail maximises prep and plating space.
- 12" (305 mm) section stamped drip trays with dimple-bottom design and 4-1/4" (108 mm) front grease trough simplify cleanup.
- Stainless steel front, sides, 2-piece backguard and removable high shelf resist corrosion and daily wear.
- 6" (152 mm) adjustable stainless legs included; optional swivel casters with front locks available.
- Factory-supplied gas regulator and 3/4" NPT rear connection; field convertible for Natural or Propane gas.
Performance & Capacity
| Total Input | 182,000 BTU / 53.3 kW |
|---|---|
| Open Burners | 4 × 32,000 BTU = 128,000 BTU |
| Griddle Burners | 3 × 18,000 BTU = 54,000 BTU |
| Griddle Plate | 36" W × 23" D × 5/8" thick smooth steel |
| Work-Top Depth | 27" / 686 mm |
| Storage Bases | 2 × 26" wide open compartments |
Dimensions & Utilities
| Overall Width | 60" / 1500 mm |
|---|---|
| Overall Depth | 34-1/2" / 876 mm |
| Overall Height | 57" / 1448 mm (with backguard & shelf) |
| Gas Connection | 3/4" NPT (rear, left-hand) |
| Manifold Pressure | 4.5" WC Natural • 10" WC Propane |
| Installed Clearances* | Combustible: 14" (sides) • 6" (rear) |
| Shipping Weight | ≈ 681 lb / 309 kg |
*Check local codes for specific installation requirements.
Certifications
- CSA Flame
- CSA Star
- cCSAus
- NSF Listed
Commercial use only. This appliance is not approved for residential installations. When installing on casters, a factory-approved restraining device must be used.
Need thermostatic griddle controls, convection ovens or caster kits? Talk to our team about custom Garland U-Series configurations.
$7,538.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Garland U60-4G36SS 60" U Series gas range: 182k BTU, four 32k burners, 36" griddle, stainless steel, storage bases, NSF certified for commercial kitchens.
Manufacturer
Garland
Brand name
US Range U Series Ranges
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
57.0in
Width
59.1in
Depth
34.5in
Shipping Weight
681.0lbs
Vent
backriser with hi-shelf
Top
(4) open burners, (1) 36" griddle
Base
(2) cabinets
Plate Thickness
.625" = 5/8"
Control Type
manual controls
Exterior Finish
stainless steel front & sides
Specifications
U Series Restaurant Range, gas, 60", (4) 32,000 BTU open burners, 36" x 23" x 5/8" thick smooth steel griddle plate, manual control, (2) storage bases, stainless steel front, sides, plate rail, 2-piece back guard and shelf, 6" stainless steel legs with adjustable feet, 182,000 BTU, CSA Flame, CSA Star, cCSAus, NSF (US Range)
Contact Us
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
