Garland U60-10SS US Range U Series Ranges Gas Ranges
Description
Garland U.S. Range U-Series 60" Gas Restaurant Range
Model U60-10SS – 10 Open Burners with Dual Storage BasesBuilt for the busiest commercial kitchens, the Garland U-Series 60" range delivers blistering heat, rock-solid durability, and the flexibility chefs demand. Ten powerful 32,000 BTU open burners sit beneath split, ergonomic cast-iron grates, while two full-width storage bases keep sheet pans, stock pots, and utensils within easy reach.
Key Features
- 320,000 BTU total output – (10) 32,000 BTU two-piece cast-iron burners for fast boiling, searing & sautéing.
- Extra-deep 27" (686 mm) work top maximizes usable cooking space.
- Dual open storage bases (in lieu of ovens) – ideal for dry pans, sheet trays, smallwares and more.
- Stainless steel front, sides, 5" plate rail and two-piece backguard with removable shelf for easy cleanup and added mise-en-place.
- 6" (152 mm) adjustable stainless legs provide a level stance on uneven floors.
- Large, easy-grip control knobs and factory-installed gas pressure regulator for quick, precise adjustments.
- CSA Flame & Star, cCSAus and NSF-listed for worry-free code compliance.
Performance Benefits
- Two-piece burner design lifts off without tools, speeding nightly cleaning.
- Geometric burner ports ensure even flame distribution across pan bottoms.
- Split top-ring grates let you slide heavy stock pots from burner to burner without lifting.
- Wide 4-1/4" front grease trough channels spillage away from the flame zone.
At-a-Glance Specifications
| Overall width | 59-1/16" / 1500 mm |
|---|---|
| Overall depth | 34-1/2" / 876 mm |
| Work top height | 36-1/2" / 927 mm to cooking surface |
| Backguard height | 57" / 1448 mm (standard high shelf) |
| Number of open burners | 10 |
| Burner rating | 32,000 BTU each (Natural gas) 26,000 BTU each (Propane) |
| Total input (Natural) | 320,000 BTU/hr • 93.7 kW |
| Gas connection | 3/4" NPT rear manifold Manifold pressure – 4.5" WC Natural • 10" WC LP |
| Base configuration | (2) full-width stainless storage compartments |
| Construction | Stainless front/sides, aluminized steel base interior, cast-iron grates |
| Shipping weight | ≈ 581 lb / 264 kg |
| Certifications | CSA Flame, CSA Star, cCSAus, NSF |
Ideal Applications
- Full-service restaurants & hotel kitchens
- Catering & banquet production lines
- Institutional, hospitality or any operation that needs high-volume sauté capacities without ovens
Need a convection-oven base, griddle sections or custom configurations? Explore the complete Garland U-Series lineup or contact our team for a tailored quote.
