Garland U48-G48SS US Range U Series Ranges Gas Ranges
$8,140.00
Unit price
/
Unavailable
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Garland U48-G48SS US Range U Series Ranges Gas Ranges is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Garland U48-G48SS US Range U Series Ranges Gas Ranges
$8,140.00
Unit price
/
Unavailable
Description
Garland U-Series 48" Gas Restaurant Range – Full-Width Griddle & Dual Storage Base
Model U48-48GSS | 72,000 BTUMaximize your cooking surface and streamline workflow with the Garland/US Range U-Series 48" restaurant range. A heavy-duty, full-width griddle rides above two spacious storage compartments—perfect for kitchens that need agile production capacity without the footprint or energy draw of ovens.
Why You’ll Love It
- 5/8" (15 mm) smooth steel griddle plate spans the entire 48" (1219 mm) width for uninterrupted, high-volume cooking.
- Four independent 18,000 BTU cast-iron “H” burners (72,000 BTU total) deliver rapid recovery and precise manual HI/LO control.
- 23" (584 mm) deep cooking surface plus a generous 4-1/4" (108 mm) front grease trough and stamped drip trays for fast clean-up.
- Two open storage bases keep sheet pans, hotel pans or smallwares within arm’s reach—no pre-heat time, no hot doors.
- All-stainless exterior (front, sides, 5" plate rail, two-piece backguard & removable shelf) stands up to daily punishment.
- Large, heat-resistant control knobs and factory-installed gas regulator simplify daily operation and setup.
- 6" (152 mm) adjustable stainless-steel legs allow easy leveling and floor access beneath the unit.
- Certified to CSA Flame, CSA Star, cCSAus and NSF standards for safety and sanitation.
Technical Specifications
| Model | U48-48GSS |
|---|---|
| Gas Type | Natural Gas (field-convertible to LP with kit) |
| Total Input | 72,000 BTU/h (21.1 kW) |
| Griddle Surface | 48" W × 23" D, 5/8" thick smooth steel |
| Burners | 4 × 18,000 BTU cast-iron “H” burners, individually valved |
| Work-Top Depth | 27" (686 mm) |
| Overall Dimensions (W × D × H) | 47-1/4" × 34-1/2" × 57"* *height to top of backguard shelf |
| Base Configuration | 2 open storage compartments (no ovens) |
| Plate Rail Height | 5" (127 mm) |
| Legs | 6" (152 mm) stainless-steel, adjustable |
| Utility Connection | 3/4" NPT rear gas inlet, regulator supplied |
| Construction | All-stainless front, sides, plate rail, backguard & shelf |
| Certifications | CSA Flame, CSA Star, cCSAus, NSF |
Commercial use only: Gas ratings are for installations up to 2,000 ft (610 m) elevation—please advise if higher.
When supplied with casters, a factory-approved restraining device must be installed.
Features & Specs
Features & Specs
Manufacturer
Garland
Brand_name
US Range U Series Ranges
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
57.0in
Width
48.0in
Depth
34.5in
Shipping Weight
522.0lbs
Plate Thickness
.625" = 5/8"
Exterior Finish
stainless steel front & sides
Base
(2) cabinets
Top
(1) griddle
Vent
backriser with hi-shelf
Specifications
U Series Restaurant Range, gas, 48", (1) griddle with 5/8" thick smooth steel plate, (2) storage bases, stainless steel front, sides, plate rail, 2-piece back guard and shelf, 6" stainless steel legs with adjustable feet, 72,000 BTU, CSA Flame, CSA Star, cCSAus, NSF (US Range)
