Garland U48-6G12SS US Range U Series Ranges Gas Ranges
Description
U Series 48" Gas Restaurant Range – 6 Burners / 12" Griddle / Dual Storage Base
Model U48-6G12SS | Garland / U.S. RangeBuilt for the high-output demands of modern commercial kitchens, this 48-inch U Series gas range pairs six lightning-fast open burners with a precision 12" steel-plate griddle and two roomy storage cabinets—delivering 210,000 BTU of total cooking power in a single, easy-to-clean platform.
Key Advantages
- Six 32,000 BTU cast-iron open burners with two-piece geometric heads for rapid boil, sauté & sear.
- 12" (305 mm) griddle section with 5/8" (15 mm) thick steel plate and manual Hi/Lo valve for exacting temperature control.
- 4-1/4" (108 mm) extra-wide grease trough & stamped drip trays for mess-free operation.
- Two open storage bases replace traditional ovens—ideal for sheet pans, smallwares or bulk ingredient bins.
- Spacious 27" (686 mm) deep work top maximises plating & prep space.
- Rugged stainless-steel front, sides, 5" (127 mm) plate rail, and two-piece backguard with removable shelf.
- 6" (152 mm) stainless legs with adjustable feet; optional locking casters available.
- Large, easy-grip control knobs and factory-installed gas regulator for worry-free setup.
At-a-Glance Specifications
| Overall width | 47-1/4" (1200 mm) |
|---|---|
| Overall depth | 34-1/2" (876 mm) | 27" (686 mm) work-surface depth |
| Height | 57" (1448 mm) with standard backguard/shelf |
| Open burners | (6) × 32,000 BTU cast-iron burners • 192,000 BTU total |
| Griddle burner | (1) × 18,000 BTU cast-iron “H” burner • 12" W × 23" D cooking surface |
| Total input | 210,000 BTU/hr (Natural Gas) |
| Gas connection | 3/4" NPT (rear) |
| Manifold pressure | Natural 4.5" WC | LP 10" WC |
| Construction | Stainless front, sides, rail & backguard; split ergonomic cast-iron top grates |
| Certifications | CSA Flame, CSA Star, cCSAus, NSF |
| Shipping weight | Approx. 432 lb (196 kg) |
Ideal For
- Full-service and fast-casual restaurants
- Catering commissaries & ghost kitchens
- Hotels, resorts & banqueting operations
- Institutional kitchens seeking maximum versatility in minimal floor space
Gas ratings shown for installations up to 2,000 ft (610 m) above sea level. Specify altitudes over 2,000 ft at time of order. Not approved for residential use.
