Garland  |  US Range U Series Ranges  |  SKU: U48-4G24SS

Garland U48-4G24SS US Range U Series Ranges Gas Ranges

$7,310.00
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Cutsheet Cutsheet Owner's manual
Related Searches
Commercial Gas Ranges Commercial Ranges Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Garland U Series 48" Gas Restaurant Range – 4 Open Burners & 24" Griddle

Model U48-4G24SS | 162,000 BTU total

Purpose-built for high-volume kitchens, the Garland U Series 48" combination range delivers the power of four 32,000 BTU open burners and the versatility of a full-size 24" griddle, all in a rugged stainless package with two roomy storage bases in lieu of ovens. Keep critical cookware at arm’s reach while turning out breakfast, lunch and dinner with the consistency chefs expect from Garland.

Key Performance Features

  • 4 × 32,000 BTU two-piece cast-iron open burners with split ergonomic top grates for easy pan movement
  • 24" wide, 5/8" thick steel griddle plate (23" working depth) powered by 2 × 18,000 BTU cast-iron “H” burners
  • Extra-large 27" deep work surface and 5" stainless plate rail maximize plating and prep space
  • Twin open storage bases (right & left) replace ovens—ideal for hotel pans, sheet pans and smallwares
  • Durable stainless steel front, sides, plate rail, and two-piece backguard with removable shelf
  • 6" stainless steel legs with adjustable feet for simple leveling on any floor
  • Front-serviceable, stamped drip trays with dimpled bottoms for fast clean-outs
  • Large, easy-grip gas valves and factory-supplied regulator for precise flame control
  • Field-convertible for Natural Gas or Propane
  • Certified: CSA Flame, CSA Star, cCSAus & NSF

Specifications

Overall width 47-1/4" / 1200 mm (48" class)
Overall depth 34-1/2" / 876 mm  •  Work top depth 27"
Overall height 57" / 1448 mm with high shelf
Open burners 4 × 32,000 BTU (Natural)  •  128,000 BTU combined
Griddle 24" W × 23" D, 5/8" plate  •  36,000 BTU (2 × 18,000)
Total input ≈ 162,000 BTU/hr Natural Gas (164,000 BTU nominal)
Gas connection 3/4" NPT rear manifold  •  4.5" WC Natural  •  10" WC LP
Shipping weight ≈ 497 lb / 225 kg
Certifications CSA Flame, CSA Star, cCSAus, NSF

Popular Options & Accessories

  • 6" locking swivel casters in place of legs
  • Flanged deck-mount legs for marine or seismic installations
  • Hot-top plate (12") in lieu of two open burners
  • Snap-action modulating griddle thermostat (175 – 425 °F)
  • Celsius temperature dials
  • Piezo spark ignition for griddle pilots
Commercial use only: Garland ranges are not approved for residential installations. Units supplied with casters must be secured with an approved restraining device. For elevations above 2,000 ft (610 m), specify when ordering so that burners may be properly derated.

Need a different burner/griddle/oven configuration? The U Series is modular—contact us for a custom quote.

Features & Specs

Manufacturer

Garland

Brand_name

US Range U Series Ranges

Certifications

NSF, cCSAus, CSA Star, CSA Flame

Height

57.0in

Width

48.0in

Depth

34.5in

Shipping Weight

497.0lbs

Plate Thickness

.625" = 5/8"

Exterior Finish

stainless steel front & sides

Base

(2) cabinets

Top

(4) open burners, (1) 24" griddle

Vent

backriser with hi-shelf

Specifications

U Series Restaurant Range, gas, 48", (4) 32,000 BTU open burners, (1) 24" griddle, 5/8" thick steel plate, (2) storage bases, stainless steel front, sides, plate rail, 2-piece back guard and shelf, 6" stainless steel legs with adjustable feet, 162,000 BTU, CSA Flame, CSA Star, cCSAus, NSF (US Range)
