Garland U36-G36R US Range U Series Ranges Gas Ranges
$5,223.00
Unit price
/
Unavailable
Description
U.S. Range U-Series 36" Gas Restaurant Range
Model U36-G36R • 92,000 BTU | Full-Top 36" Griddle | Standard OvenBuilt for busy line kitchens that refuse to compromise on performance, the Garland / U.S. Range U-Series 36" restaurant range unites a heavy-duty 5/8" steel griddle, fast-recovery oven and all-stainless construction in a single, service-friendly platform.
Why You’ll Love It
- 36" wide smooth 5/8" (15 mm) steel griddle plate – perfect for breakfast, burgers & more.
- 92,000 BTU/hr total input (Natural gas) delivers rapid heat-up & recovery.
- Three 18,000 BTU cast-iron “H” style griddle burners with manual hi/lo valve control.
- 38,000 BTU cast-iron oven burner with snap-action thermostat (Low – 500 °F).
- Full-size oven fits 18" × 26" sheet pans either direction; includes 1 nickel-plated rack & 3-position guides.
- Rugged stainless steel front, sides, 5" plate rail and 2-piece backguard with removable shelf.
- Stay-cool, heavy-duty oven door handle and large, easy-grip control knobs.
- Front-serviceable griddle plate with 4-1/4" wide grease trough for quick clean-up.
- 6" adjustable stainless steel legs make leveling a breeze.
- Safety & sanitation peace of mind: CSA Flame, CSA Star, cCSAus & NSF listed.
Performance at a Glance
| Overall width | 35-7/16" (900 mm) |
|---|---|
| Overall depth | 34-1/2" (876 mm) |
| Height w/ standard backguard & shelf | 57" (1448 mm) |
| Work-top depth | 27" (686 mm) |
| Griddle cooking surface | 36" W × 23" D (914 × 584 mm) |
| Griddle plate thickness | 5/8" (15 mm) smooth steel |
| Total input – Natural gas | 92,000 BTU/hr (27 kW) |
| Oven interior (W × D × H) | 26" × 26-1/4" × 14" (660 × 667 × 356 mm) |
| Gas connection | 3/4" NPT (rear), 4.5" WC – Nat | 10" WC – LP |
| Shipping weight | 530 lb (240 kg) |
Built for the Long Haul
- Double-wall oven door with porcelain-lined interior for durability and easy cleaning.
- Reinforced chassis corners withstand daily rigors of a high-volume line.
- Front-located oven pilot for quick access & lighting.
- Optional convection oven, low-profile backguard, casters and more (factory-installed).
Certifications & Approvals
- CSA Flame & CSA Star (gas safety & performance)
- cCSAus (Canada & U.S.)
- NSF (sanitation)
Commercial use only. Garland / U.S. Range equipment is not approved for residential
installation.
Features & Specs
Features & Specs
Manufacturer
Garland
Brand_name
US Range U Series Ranges
Certifications
NSF, cCSAus, CSA Star, CSA Flame
Height
57.0in
Width
36.0in
Depth
34.5in
Shipping Weight
530.0lbs
Exterior Finish
stainless steel front & sides
Plate Thickness
.625" = 5/8"
Top
(1) griddle
Base
(1) standard oven
Vent
backriser with hi-shelf
Specifications
U Series Restaurant Range, gas, 36", griddle, 5/8" thick smooth steel plate, standard oven, (1) oven rack, 3 position rack guides, stainless steel front, sides, plate rail, 2-piece back guard & shelf, 6" stainless steel legs, adjustable feet, 92,000 BTU, CSA Flame, CSA Star, cCSAus, NSF (US Range)
