Garland

Garland master series heavy duty 34-inch modular gas range top with electric ignition, 2 open burners, and 17-inch hot top

SKU: MST54T-E
$6,614.10
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best sellers Commercial ranges Garland Gas ranges New arrivals Ranges Restaurant equipment

Garland Master Series Heavy Duty 34-Inch Modular Gas Range Top with Electric Ignition, 2 Open Burners, and 17-Inch Hot Top

Stainless Steel Front & Sides, Flame Failure Protection

This compact 34-inch modular gas range top delivers a versatile combination of two open burners and a 17-inch hot top with electric ignition for busy commercial kitchens.

  • 34-inch modular gas range top with two open burners and one 17-inch front-fired hot top.
  • 115,000 BTU total input supports demanding commercial cooking.
  • Electric spark ignition and flame-failure protection help support safer operation.
  • Stainless steel front and sides are built for heavy-use kitchens.
  • Natural gas or propane can be specified when ordering.
  • 115V, 60Hz, 1-phase ignition with NEMA 5-15P plug on suffix -E models.

Overall Dimensions:

34.0"W x 38.0"D x 9.5"H

Product Weight:

270.0 lb

Modular Top Design

Top-only modular section designed for flexible installation in a commercial range line.

Two Open Burners

Includes two open burners for high-output sautéing, boiling, and general-purpose cooking.

Front-Fired Hot Top

The 17-inch front-fired hot top adds a dedicated cooking surface for stock pots and pans.

Electric Spark Ignition

Suffix -E models include electric spark ignition on all pilots for reliable starting.

Flame Failure Protection

Sentry flame-failure protection helps shut off gas if a flame goes out.

Stainless Steel Construction

Stainless steel front and sides help resist wear and simplify cleanup.

Heavy-Duty Cast Iron Surfaces

Cast iron top grates and ring grates provide rugged support for heavy cookware.

Gas Flexibility

Can be ordered for natural gas or propane; specify the fuel type when ordering.

Type Gas Range Top
Style Modular Top
Installation Type Countertop
Material Stainless Steel
Finish Stainless Steel
BTU 115,000 BTU
Gas Connection Size 1-1/4 Inches NPT
Voltage 115 Volts
Amps 0.1 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Shipping Width 34 Inches
Shipping Depth 38 Inches
Shipping Height 10 Inches
Shipping Weight 270 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Check list PDF Download PDF Owner's manual PDF Download

Frequently Asked Questions

No. MST54T-E is the modular top version of the range and does not include an oven.
It includes two open burners and one 17-inch front-fired hot top.
Natural gas or propane can be specified when ordering.
The suffix -E models use 115V, 60Hz, single-phase power at 0.1 amps with a NEMA 5-15P cord and plug on models without an RC oven.
Operating pressure is 6 inches W.C. for natural gas and 10 inches W.C. for propane.
Yes. The documentation notes that ranges supplied with casters must be installed with an approved restraining device.
