Garland Master Series 34" Modular Heavy-Duty Gas Griddle Top
Model M48T • 99,000 BTU • Thermostatic ControlsDrop powerful, pinpoint heat exactly where you need it. Built for the Garland Master Series battery line-up, the low-profile M48T griddle top delivers a full 99,000 BTU of searing performance through three independent, thermostat-controlled “H” burners – all inside a rugged stainless-steel chassis that thrives in the busiest commercial kitchens.
Key Advantages
- 1" (25 mm) polished steel griddle plate for outstanding heat retention and fast recovery.
- Three heavy-duty “H” burners – 33,000 BTU each / 99,000 BTU total.
- Independent thermostatic controls with embedded capillary sensors for precise zone cooking.
- Low-profile modular design (9.5" H) installs on a refrigerated base, chef’s counter or equipment stand.
- Welded 2 ⅚" splash guards plus clip-on stainless backsplash keep grease contained.
- Front-mounted, removable stainless-steel grease drawer for quick, safe clean-up.
- 7 ½" deep stainless front rail offers a handy plating surface and shields controls.
- Stainless-steel front & sides withstand daily abuse and wipe clean in seconds.
- Field-convertible for Natural or Propane gas.
- Certified to CSA Flame, CSA Star & NSF standards for gas safety and sanitation.
At-a-Glance Specifications
| Cooking surface | 34" W × 26 ⅞" D (864 × 683 mm) (38" overall depth incl. front rail) |
|---|---|
| Plate thickness | 1" (25 mm) steel |
| Total gas input | 99,000 BTU/hr • 29 kW |
| Number of burners | 3 cast-iron “H” burners |
| Controls | 3 independent thermostats, 200–550 °F (93–288 °C) |
| Gas connection | 1 ¼" NPT front (standard) • Optional rear connection kit |
| Operating pressure | Natural 6" WC • Propane 10" WC |
| Overall dimensions | 9 ½" H × 34" W × 38" D (241 × 864 × 965 mm) 36 ⅜" H with optional stand & NSF legs |
| Shipping weight | 410 lb (186 kg) |
| Certifications | CSA Flame, CSA Star, NSF |
Popular Options & Accessories
- Stainless-steel or refrigerated equipment stand
- Rear gas connection kit (¾" or 1" NPT)
- Common front rail for battery installations (up to 102")
- Fully grooved or sectionally grooved plate
- Single or double-deck tubular overshelf
- Backguards: 10", 17" or 33" stainless-steel
- Gas flex hose & quick-disconnect with restraining device
- Set of four non-marking swivel casters with front brakes
Installation Note: All Master Series modules require a backguard and must be installed beneath an
appropriate ventilation hood. Gas equipment should be connected and restrained by a licensed professional
in accordance with local codes.
Commercial use only — not for residential installation. For elevations above 2,000 ft (610 m), consult factory for burner deration.
$6,979.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to
?
Garland M48T 34" Master gas range: heavy-duty modular design, 99,000 BTU, griddle, thermostatic controls, stainless steel, NSF/CSA certified.
Manufacturer
Garland
Brand name
Master
Certifications
NSF, CSA Star, CSA Flame
Height
36.38in
Width
34.0in
Depth
38.0in
Shipping Weight
300.0lbs
Plate Thickness
1.000" = 1"
Top
(1) griddle with thermostat
Exterior Finish
stainless steel front & sides
Base
modular
Specifications
Master Series Heavy Duty Range, gas, 34", modular, griddle, thermostatic controls, stainless steel front & sides, 99,000 BTU, CSA Flame, CSA Star, NSF (Garland)
