Garland M45T Master Gas Ranges
Description
Garland Master Series M45T Modular Front-Fired Hot Top Range – 34"
Heavy-Duty • 90,000 BTU Natural Gas • 2 × 17" Cast-Iron Hot TopsPurpose-built for high-volume commercial kitchens, the Garland M45T delivers intense, even heat from two extra-heavy 17″ hot-top sections while fitting seamlessly into a battery of Master Series equipment. Its modular design drops into a counter, chef’s line or custom stand, giving you Garland power exactly where you need it—without sacrificing space for an oven or storage base.
Why You’ll Love It
- 90,000 BTU/hr total output (Natural Gas) or 66,000 BTU/hr (Propane).
- (2) 17″ front-fired Spectro-Heat™ hot-top sections, each with three individually controlled jet burners for true zone cooking.
- Removable cast-iron rings & lids let you go from gentle simmer to full-tilt stock-pot duty in seconds.
- Extra-heavy cast-iron cooking surface holds heat and shrugs off daily abuse.
- One-piece stainless-steel drip tray spans the full width for fast clean-ups.
- Stainless-steel front & sides stand up to corrosive kitchen environments and wipe clean with ease.
- 7-1/2″ deep stainless front rail doubles as a plating shelf and pot rest.
- Heavy-gauge aluminized-steel radiation baffle system maximises burner efficiency.
- Piezo spark ignition—no pilot re-lighting required.
- 1-1/2″ seating flanges simplify drop-in installation; optional stand, legs, casters and backguards available.
Technical Specs
| Model | Garland M45T (Modular Top) |
|---|---|
| Gas Type | Natural Gas or Propane (specify at order) |
| Total Input | 90,000 BTU/hr (Natural) | 66,000 BTU/hr (Propane) |
| Hot-Top Sections | (2) × 17″ cast-iron, 3 jet burners per section, independent controls |
| Overall Width | 34″ / 864 mm |
| Overall Depth | 38″ / 965 mm |
| Height | 9-1/2″ / 241 mm (module only) | 36-3/8″ / 924 mm with optional stand/legs |
| Front Gas Connection | 1-1/4″ NPT (rear connection optional) |
| Manifold Pressure | 6″ WC Natural | 10″ WC Propane |
| Combustible Clearances* | Sides 14″ / 356 mm | Rear 6″ / 152 mm |
| Shipping Weight | ≈ 305 lb / 138 kg |
| Certifications | NSF & CSA (Commercial gas equipment) |
*Clearances are for units installed with approved backguard.
Popular Options & Accessories
- Stainless-steel backguards: 10″, 17″ or 33″ heights.
- Single or double-deck tubular high shelves.
- 6″ adjustable stainless legs, dais base or non-marking swivel casters with brakes.
- Rear gas connection kits (¾″ or 1-¼″ NPT) with shut-off valve & flex hose.
- Battery-rail kits for a continuous common front rail up to 102″.
- End caps & covers for flush battery installations.
